Description
With the 4x4 HDMI matrix switch, you can choose between four HDMI signal sources and send them to four different HDMI outputs, independently or simultaneously. All HDMI ports can be assigned to other HDMI outputs, or to all of them, at your convenience. Easy to control with a remote control, the device, RS232, telnet or a web interface. There are further configurations available via the web interface. For example, connect your Blu-Ray player, satellite receiver or gaming console at the same time and select the devices you would like to display using the remote control.
DIGITUS Professional DS-43306 4K HDMI Matrix Switch 4x4 / Video | DS-43306
Special Features
- Supports UHD resolutions up to 4K / 60 Hz
- Every HDMI input can be assigned to every HDMI output
- Output of up to four HDMI signals to four HDMI monitors simultaneously or independently
- The HDMI inputs can be assigned to outputs as desired - even in parallel
- Switch all HDMI connections easily with a remote control, RS232, telnet, web interface or the device itself
- Configuration is also possible via a web interface and RS232
- Supports HDCP 2.2
- Supports storing and retrieving up
Product Specification
Device Type | Video/audio switch - 4 ports |
Enclosure Type | Desktop |
Subtype | HDMI |
Remote Management Protocol | Telnet |
Max Resolution | 4096 x 2160 @ 60 Hz |
Max Video Bandwidth | 600 MHz |
Features | HDCP compliant, 3D support, 4K resolution support, LPCM 7.1 support, 48-bit Deep Colour support, HDR support |
Compliant Standards | HDCP 2.2 |
Interfaces | 4 x HDMI output Type A ¦ 4 x HDMI input Type A ¦ 1 x serial (RS-232) ¦ 1 x management RJ-45 |
Power Device | External power adapter |
Power Provided | 12 V - 2 A |
Colour | Black |
Included Accessories | Wireless remote control |
Width | 27 cm |
Depth | 12.2 cm |
Height | 2.5 cm |
Weight | 787.5 g |
Shipping Width | 28.5 cm |
Shipping Depth | 21.4 cm |
Shipping Height | 5 cm |
Shipping Weight | 1.05 kg |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 50 °C |
Humidity Range Operating | 0 - 95% (non-condensing) |
