Gigabyte BRIX GB-BACE-3160 (rev. 1.0) / Barebone / Ultra Compact PC Kit / 1 x Celeron J3160 / 1.6 GHz / RAM 0 GB / HD Graphics 400 / GigE | GB-BACE-3160

GB-BACE-3160
156.43
(186.15 inc. VAT)
Out of stock
Find similar
Delivery
Payment options
Product Code03:106122 EAN Code4719331216719 ManufacturerGigaByte CPU TypeIntel Celeron

Product Features

  • Intel Celeron processor
    Based on the Silvermot micro-architecture which utilizes the 14nm process technology, these SoC feature significant improvements in computational power, energy efficiency, enhanced graphical and media performance making the BRIX ideal for thin clients, retail transactional clients, and digital signage.
  • Advanced features for power users
    The Brix is engineered to take full advantage of what the hardware and its UEFI BIOS are capable of. And therefore, it's designed to deliver the most intuitive and integrated operating systems in the world.
  • VESA support
    The BRIX is packed with wall mount adapter whether undergo rigorous testing for safety and reliability. The BRIX also bundled with a VESA bracket, it can easily be mounted behind a monitor or HDTV making it discreetly hidden from view. This offers a simple and elegant way to turn any VESA-compliant display or TV into a full-featured PC or digital signage unit.

Special Features

  • Intel Celeron processor
  • Advanced features for power users
  • VESA support

Product Specification

Type PC barebone
Product Form Factor Ultra Compact PC Kit
Processor / Chipset Processor / Chipset
CPU Intel Celeron J3160 / 1.6 GHz
Max Turbo Speed 2.24 GHz
Number of Cores Quad-Core
CPU Qty 1
Max CPU Qty 1
Cache Memory Cache Memory
Installed Size 2 MB
Cache Per Processor 2 MB
RAM RAM
Installed Size 0 GB / 8 GB (max)
Technology DDR3L SDRAM
Form Factor SO-DIMM 204-pin
Slots 1 (Total) / 1 (empty)
Hard Drive Hard Drive
Type No HDD
Storage Controller Storage Controller
Type 1 x SATA
Controller Interface Type SATA 6Gb/s
Channel Qty 1
Optical Storage Optical Storage
Type No optical drive
Card Reader Card Reader
Type Card reader
Supported Flash Memory Cards microSD
Monitor Monitor
Monitor Type None.
Graphics Controller Graphics Controller
Graphics Processor Intel HD Graphics 400
Video Interfaces VGA, HDMI
Max Monitors Supported 2
Audio Output Audio Output
Sound Output Mode Stereo
Networking Networking
Ethernet Controller Realtek RTL8111H
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
Expansion / Connectivity Expansion / Connectivity
Bays 1 (total) / 1 (free) x internal 2.5"
Slots 1 (total) / 1 (free) x SO-DIMM 204-pin ¦ 1 M.2 Card - 2230
Interfaces 4 x USB 3.0 (2 front, 2 rear) ¦ 1 x HDMI ¦ 1 x VGA ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x headphones - mini-jack ¦ 1 x microphone - mini-jack
Miscellaneous Miscellaneous
Included Accessories VESA wallmount adapter
Theft/Intrusion Protection Security lock slot (cable lock sold separately)
VESA Mounting Interface 100 x 100 mm, 75 x 75 mm
Power Power
Device Type Power adapter
Nominal Voltage AC 120/230 V
Operating System / Software Operating System / Software
OS Provided No operating system
Dimensions & Weight Dimensions & Weight
Width 10.76 cm
Depth 11.44 cm
Height 5.61 cm
Environmental Parameters Environmental Parameters
Min Operating Temperature 0 °C
Max Operating Temperature 35 °C

Features - GigaByte - GB-BACE-3160

CPU Type
  • Intel Celeron
More Details
Product Code
03:106122
EAN Code
4719331216719
Manufacturer
GigaByte
