MSI Z170M MORTAR / Motherboard / micro ATX / LGA1151 Socket / Z170 / USB 3.1 Gen1 / Gigabit LAN / onboard graphics (CPU required) / HD Audio (8-channel) | 7972-001R
|
Description The MSI Z170 Arsenal GAMING series are forged to provide a non-stop gaming experience with an arsenal of crucial gaming features included. Stay ahead of the enemy with MSI GAMING LAN, enjoy the sparkling sound quality of Audio Boost and set the mood with Ambient Light. Specifically suited for the stealthy smaller gaming systems, the mATX MSI Z170M MORTAR offers a full range of features for the casual gamer. Special Features
|
Product Specification
| Product Type | Motherboard - micro ATX |
| Chipset Type | Intel Z170 |
| Processor Socket | LGA1151 Socket |
| Max Processors Qty | 1 |
| Compatible Processors | Pentium, Celeron, Core i5, Core i3, Core i7 |
| Max Size | 64 GB |
| Technology | DDR4 |
| Bus Clock | 2400 MHz, 2133 MHz, 2800 MHz (O.C.), 2600 MHz (O.C.), 3000 MHz (O.C.), 3200 MHz (O.C.) |
| Registered or Buffered | Unbuffered |
| Features | Dual channel memory architecture, Intel Extreme Memory Profiles (XMP) |
| Type | HD Audio (8-channel) |
| Audio Codec | Realtek ALC892 |
| Compliant Standards | High Definition Audio |
| Network Controller | Realtek RTL8111H |
| Network Interfaces | Gigabit Ethernet |
| Expansion Slots | 1 x CPU ¦ 4 x DIMM 288-pin ¦ 2 x PCIe 3.0 x16 (x16/x4 mode) ¦ 2 x PCIe 3.0 x1 ¦ 1 x M.2 socket |
| Storage Interfaces | SATA-600 -connectors: 6 x 7pin SATA, 1 x SATA Express port - RAID 0 / RAID 1 / RAID 10 / RAID 5 |
| RAID Features | Intel Smart Response Technology |
| Interfaces | 1 x LAN (Gigabit Ethernet) ¦ 1 x DVI-D ¦ 1 x VGA ¦ 1 x HDMI ¦ 1 x audio line-out (rear) - mini-jack ¦ 1 x audio line-out - mini-jack ¦ 1 x audio line-in - mini-jack ¦ 1 x microphone - mini-jack ¦ 2 x USB 2.0 ¦ 1 x audio line-out (center/subwoofer) - mini-jack ¦ 1 x PS/2 keyboard / mouse ¦ 4 x USB 3.1 Gen1 ¦ 1 x TOSLINK |
| Internal Interfaces | 2 x USB 2.0 - header ¦ 4 x USB 3.1 Gen1 - header ¦ 1 x audio - header ¦ 1 x serial - header |
| Power Connectors | 24-pin main power connector, 8-pin ATX12V connector |
| BIOS Features | UEFI BIOS, MSI ClickBIOS 5 |
| Hardware Features | Intel Extreme Memory Profile (XMP) support, AMD CrossFireX technology support, MSI Military Class IV, MSI Audio Boost, Clear CMOS Button, MSI Guard-Pro, Debug LED, MSI Steel Armor, SteelSeries Certified (SSC) |
| Included Accessories | I/O back cover |
| Software Included | RAMdisk, MSI Gaming Hotkey, MSI Gaming LAN Manager |
| Width | 24.4 cm |
| Depth | 24.4 cm |
