TallyGenicom 5040 / Passbook printer / monochrome / dot-matrix / 240 x 500 mm / 360 x 180 dpi / 24 pin / up to 600 char/sec / parallel, USB, serial | 043379
TallyGenicom 5040 / Passbook printer / monochrome / dot-matrix / 240 x 500 mm / 360 x 180 dpi / 24 pin / up to 600 char/sec / parallel, USB, serial | 043379
Description With up to 400 characters per second (cps) at 10 cpi, the 5040 rapidly processes media of diverse types ranging from passbooks and checks to A5 receipts and A4 information needs.The printer's flatbed design provides totally assured paper handling, and with advanced features such as Automatic Paper Alignment and Automatic Gap Adjustment (AGA), they offer unsurpassed ease-of-use. Using Serial Impact technology - the most reliable and versatile method available for producing print - the 5040 is a durable, robust, dependable printer that supports a wide range of printing applications.The standard 5040 supports cut forms via a serial interface connection and a secure command language, as demanded within the banking environment. As standard, USB and Parallel interfaces are included for flexibility of connection and single-station, multi-user operation. A second, plug in, serial interface is available as an upgrade option. Special Features
|
Product Specification
Printer Type | Passbook printer - dot-matrix - 24 pin - monochrome |
Print Speed | Up to 600 char/sec - fast draft - 15 cpi ¦ Up to 480 char/sec - fast draft - 12 cpi ¦ Up to 400 char/sec - fast draft - 10 cpi ¦ Up to 400 char/sec - draft - 15 cpi ¦ Up to 360 char/sec - draft - 12 cpi ¦ Up to 300 char/sec - draft - 10 cpi ¦ Up to 200 char/sec - near letter - 15 cpi ¦ Up to 160 char/sec - near letter - 12 cpi ¦ Up to 133 char/sec - near letter - 10 cpi ¦ Up to 150 char/sec - letter - 15 cpi ¦ Up to 120 char/sec - letter - 12 cpi ¦ Up to 100 char/sec - letter - 10 cpi |
Built-in Devices | Status LCD |
Connectivity Technology | Wired |
Interface | Parallel, USB, serial |
Max Resolution (B&W) | 360 x 180 dpi |
Language Simulation | EPSON ESC/P, IBM 4722, Olivetti PR2, Olivetti PR50, IBM ProPrinter XL24e, Olivetti PR2e |
Fonts Included | 1 x bitmapped ¦ 1 x barcode |
Barcodes | Code 93, Industrial 2 of 5, Code 39, EAN/JAN-8, EAN/JAN-13, UPC-A, UPC-E, Codabar, Code 128, Interleaved 2 of 5, OCR-A, OCR-B |
Printer Features | Automatic head gap adjustment |
Media Handling | Front paper feeder |
RAM Installed (Max) | 32 KB |
Media Type | Receipt paper, passbook |
Max Media Size | 240 x 500 mm |
Min Media Size (Custom) | 70 mm x 70 mm |
Max Media Size (Custom) | 240 mm x 500 mm |
Media Sizes | 70 x 70 mm, 240 x 500 mm |
Media Thickness Range | Up to 2 mm |
Media Weight | 60 g/m² - 180 g/m² |
Media Feeders | 1 x manual - 1 sheet - 240 x 500 mm weight: 60 g/m² - 180 g/m² |
Max Sheets in Multi-Part Form | 5 |
Connections | 1 x RS-232 - 9 pin D-Sub (DB-9) ¦ 1 x parallel - 36 PIN Centronics ¦ 1 x USB - 4 pin USB Type B |
Consumables Included | 1 x ribbon - up to 10 million characters ¦ 1 x printhead - up to 300 million dots |
MTBF | 10,000 hour(s) |
Compatible with Windows 7 | "Compatible with Windows 7" software and devices carry Microsoft's assurance that these products have passed tests for compatibility and reliability with 32-bit and 64-bit Windows 7. |
Compliant Standards | RoHS |
Power Device | Power supply - internal |
Voltage Required | AC 230V |
Frequency Required | 50/60 Hz |
Power Consumption Operational | 73 Watt |
Power Consumption Stand by / Sleep | 9 Watt |
ENERGY STAR | Yes |
Service & Support | Limited warranty - 1 year - carry-in |
Min Operating Temperature | 10 °C |
Max Operating Temperature | 30 °C |
Humidity Range Operating | 15 - 75% |
Sound Emission (Operating) | 55 dBA |
Width | 37.8 cm |
Depth | 27.9 cm |
Height | 16.8 cm |
Weight | 10 kg |
