Cisco AIR-ACC245LA-R 2.4/5GHZ Lightning Arrestor
2.4/5GHZ Lightning ArrestorOvervoltage transients can be created through lightning static discharges, switch processes, direct contact with power lines, or through earth currents. The Cisco Aironet AIR-ACC245LA-R Lightning Arrestor limits the amplitude and duration of disturbing interference voltages and improves the overvoltage resistance of in-line equipment, systems, and components. A lightning arrestor installed according to these mounting instructions balances the voltage potential, thus preventing inductive interference to parallel signal lines within the protected system.
The Cisco Aironet AIR-ACC245LA-R Lightning Arrestor is designed for use with Cisco Aironet access points and bridges but can be used Cisco Aironet radio device that utilizes an RP-TNC connector.
|Antenna gain level max:||20 dBi|
|Antenna connector type:||TNC-R|
|Power handling:||60 W|
|Operating temperature range T-T:||-40 - 85 °C|
