Acer U5320W / DLP projector / 3D / 3000 ANSI lumens / WXGA (1280 x 800) / 16:10 / 720p / ultra short-throw fixed lens / LAN | MR.JL111.001
Acer U5320W / DLP projector / 3D / 3000 ANSI lumens / WXGA (1280 x 800) / 16:10 / 720p / ultra short-throw fixed lens / LAN | MR.JL111.001
|
Description The Acer U5320W is an ultra-short throw projector that can be placed as close as 23cm (9.1-inches) from the projection surface, and the ability to can project up to 100-inch images at a distance of 50cm (19.7-inches), providing greater space flexibility. It also eliminates shadowing and enhances viewing comfort, a significant benefit for classrooms. The U5320W's WXGA resolution and 3,000 lumens brightness creates crystal-clear and vibrant images, while its 2x10W speakers provide powerful sound. When paired with an optional Acer SmartPen II, the U5320W is ideal for classroom settings, allowing on-screen writing from up to a 32-foot distance for up to two users, and working as a remote control to encourage interactive learning. |
Product Specification
| Device Type | DLP projector - 720p |
| 3D Capable | Yes |
| Built-in Devices | Stereo speakers |
| Microdisplay | DarkChip 3 |
| Brightness | 3000 ANSI lumens |
| Brightness (Reduced) | 2400 ANSI lumens |
| Contrast Ratio | 13000:1 (dynamic) |
| Image Size | 177 cm - 305 cm |
| Projection Distance | 0.22 m - 0.63 m |
| Throw Ratio | 0.37:1 |
| Digital Zoom Factor | 2x |
| Resolution | WXGA - WXGA (1280 x 800) (native) / 1920 x 1200 (resized) |
| Native Aspect Ratio | 16:10 |
| Colour Support | 1.07 billion colours |
| Max Sync Rate (V x H) | 120 Hz x 100 kHz |
| Bulb type | UHP 240 Watt |
| Bulb life cycle | Up to 3000 hour(s) / up to 6000 hour(s) (economic mode) |
| Features | Ultra Short Throw Technology |
| Type | Ultra short-throw fixed lens |
| Focus Type | Manual |
| Lens Aperture | F/2.53 |
| Keystone Correction Direction | Horizontal, vertical |
| Vertical Keystone Correction | -15 / +15 |
| Horizontal Keystone Correction | -15 / +15 |
| TV System | PAL, PAL-B/G, PAL-N, PAL-M, PAL-I, NTSC 4.43, NTSC 3.58, PAL-D, SECAM L, PAL-H, SECAM K1, SECAM D/K, SECAM B/G |
| Analogue video Signal | S-Video, composite video, component video |
| Video Interfaces | HDMI, composite video, S-Video |
| Video Modes | 480p, 720p, 1080i, 1080p, 480i, 576i, 576p |
| LAN and Wireless Image Transferring Protocols | Wired LAN |
| Type | Integrated |
| Sound Output Mode | Stereo |
| Output Power / Channel | 10 Watt |
| Speakers | 2 x right / left channel |
| Interfaces | 1 x USB - 4 pin mini-USB Type B ¦ 2 x Mobile High-Definition Link (MHL) / HDMI - 19 pin HDMI Type A ¦ 1 x composite video input - RCA ¦ 1 x S-video input - 4 pin mini-DIN ¦ 1 x network - RJ-45 (management) ¦ 2 x component video / RGB input - 15 pin HD D-Sub (HD-15) ¦ 2 x audio line-in ¦ 1 x microphone ¦ 1 x audio line-out - RCA x 2 ¦ 1 x VGA output ¦ 1 x audio line-out ¦ 1 x USB - 4 pin USB Type A ¦ 1 x serial RS-232 |
| Cables Included | 1 x VGA cable |
| Nominal Voltage | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 299 Watt |
| Power Consumption Stand by | 0.5 Watt |
| Weight | 5.5 kg |
| Service & Support | Limited warranty - 3 years ¦ Limited warranty - lamp - 1 year ¦ Limited warranty - DLP chipset - 5 years |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Sound Emission | 33 dBA |
| Sound Emission (Economic Mode) | 27 dBA |
