ADATA XPG SX8200 / Solid state drive / 480 GB / internal / M.2 2280 / PCI Express 3.0 x4 (NVMe) | ASX8200NP-480GT-C
ADATA XPG SX8200 / Solid state drive / 480 GB / internal / M.2 2280 / PCI Express 3.0 x4 (NVMe) | ASX8200NP-480GT-C
Description The SX8200 M.2 2280 SSD is a fast SSD to date, designed for PC enthusiasts, dedicated gamers, and overclockers. It features an ultra-fast PCIe Gen3x4 interface, offering sustained peak R/W speeds of 3200/1700 MB per second, outpacing SATA 6 Gb/s by a huge margin. NVMe 1.3 qualified, the SX8200 delivers superior random read/write performance and multi-tasking capabilities. With SLC Caching, DRAM Cache Buffer, and LDPC ECC technologies, it maintains high speeds and data integrity during even the most intense gaming, rendering, overclocking, and other high demand applications. ADATA XPG SX8200 / Solid state drive / 480 GB / internal / M.2 2280 | ASX8200NP-480GT-CSpecial Features
Product features
|
Product Specification
Device Type | Solid state drive - internal |
Capacity | 480 GB |
NAND Flash Memory Type | 3D triple-level cell (TLC) |
Form Factor | M.2 2280 |
Interface | PCI Express 3.0 x4 (NVMe) |
Features | Integrated heatsink, DRAM cache, LDPC error correction, SMI controller, 3D NAND Technology, Intelligent SLC Caching, NVM Express (NVMe) 1.3 |
Width | 22 mm |
Depth | 80 mm |
Height | 3.5 mm |
Weight | 8 g |
SSD Endurance | 320 TB |
Internal Data Rate | 3050 MBps (read) / 1700 MBps (write) |
Maximum 4KB Random Write | 280000 IOPS |
Maximum 4KB Random Read | 310000 IOPS |
MTBF | 2,000,000 hours |
Interfaces | 1 x PCI Express 3.0 x4 (NVMe) - M.2 Card |
Compatible Bay | M.2 2280 |
Power Consumption | 0.33 Watt (active) ¦ 0.14 Watt (idle) |
Compliant Standards | VCCI, BSMI, FCC, RoHS, KC |
Service & Support | Limited warranty - 5 years |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 70 °C |
Min Storage Temperature | -40 °C |
Max Storage Temperature | 85 °C |
