Allied Telesis AT X510-28GSX / Switch / L2+ / Managed / 24 x SFP + 2 x 10 Gigabit Ethernet / 1 Gigabit Ethernet SFP+ + 2 x 10 Gigabit SFP+ / rack-mountable | AT-X510-28GSX-50
Allied Telesis AT X510-28GSX / Switch / L2+ / Managed / 24 x SFP + 2 x 10 Gigabit Ethernet / 1 Gigabit Ethernet SFP+ + 2 x 10 Gigabit SFP+ / rack-mountable | AT-X510-28GSX-50
Description
The Allied Telesis x510 series of stackable gigabit edge switches have a full set of security and resiliency features, coupled with easy management, making them the ideal choice for applications at the network edge.The Allied Telesis x510 series switches are a high performing and feature-rich choice for today's networks. They offer a versatile solution for enterprise applications. With 24-port and 10 Gigabit uplink ports, plus the power of Virtual Chassis Stacking (VCStack), the x510 series can connect anything from a small workgroup right up to a large business.
Allied Telesis AT X510-28GSX / Switch | AT-X510-28GSX-50
Special Features
- Easy management
- Network resiliency
- Reliable and secure
- Future-proof
- ECO friendly
Product features
- Easy management
The x510 series runs the advanced AlliedWare Plus fully featured Operating System delivering a rich feature set and an industry-standard CLI. The CLI reduces training requirements and is consistent across all AlliedWare Plus devices, simplifying network management. - Network resiliency
The convergence of network services in the enterprise has led to increasing demand for highly available networks with minimal downtime. VCStack, in conjunction with link aggregation, provides a network with no single point of failure and an easy solution for resiliency at the network edge. The addition of EPSRing resilient ring protocol ensures distributed network segments have high speed, resilient access to online resources and applications. The x510 series can form a VCStack of up to four units for enhanced resiliency and simplified device management. Full EPSRing support and VCStack LD (Long-Distance), which enables stacks to be created over long distance fiber links, make the x510 series the perfect choice for distributed environments. - Reliable
The x510 series was designed with reliability in mind, and guarantees continual delivery of essential services. With dual built-in power supplies and near hitless online stack reconfiguration, you can maintain and reconfigure when necessary without affecting network uptime. Dual internal PSUs eliminate the need for an external Redundant Power Supply (RPS), which occupies valuable rack space. The x510 series also features front-to-back cooling, making it ideal for data center applications. - Secure
Advanced security features protect the network from the edge to the core. Unprecedented control over user access is provided with Network Access Control (NAC), to mitigate threats to network infrastructure. This ensures the network is accessed only by known users and devices - all users' adherence to network security policies is checked, and then either access is granted or remediation is offered. Secure access can also be provided for guests. A secure network environment is guaranteed. The x510 series offers powerful control over network traffic types, secure management options, Loop Guard to protect against cabling mistakes, and tri-authentication for comprehensive access control. - Future-proof
The x510 series ensures a futureproof network, with superior flexibility coupled with the ability to stack multiple units. All x510 series models come with 10 Gigabit uplinks ports and a comprehensive IPv6 feature set, to ensure they are ready for all your future network traffic demands. - ECO friendly
The x510 series supports Energy Efficient Ethernet, which automatically reduces the power consumed by the switch whenever there is no traffic on a port. This sophisticated feature can significantly reduce your operating costs, by reducing the power requirements of the switch and any associated cooling equipment.
Product Specification
Device Type | Switch - 24 ports - L2+ - Managed - stackable |
Enclosure Type | Rack-mountable 1U |
Subtype | Gigabit Ethernet |
Ports | 24 x SFP + 2 x 10 Gigabit Ethernet / 1 Gigabit Ethernet SFP+ + 2 x 10 Gigabit SFP+ |
Performance | Switching capacity: 128 Gbps ¦ Forwarding performance: 95.2 Mpps ¦ Stacking bandwidth: 40 Gbps |
Capacity | MAC addresses: up to 16000 ¦ Virtual interfaces (VLANs): 4094 ¦ IPv4 routes: up to 2000 ¦ IPv6 routes: up to 1000 |
MAC Address Table Size | 16K entries |
Jumbo Frame Support | 13KB |
Max Units In A Stack | 4 |
Routing Protocol | IGMPv2, IGMPv3, ECMP, policy-based routing (PBR), VRRPv3 |
Remote Management Protocol | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH, SSH-2, CLI |
Encryption Algorithm | DES, Triple DES, RSA, MD5, SHA-1, TLS 1.0, SSL 3.0, SSL 2.0, PEAP, TTLS |
Authentication Method | Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2), Extensible Authentication Protocol (EAP) |
Features | Flow control, BOOTP support, ARP support, VLAN support, IGMP snooping, Syslog support, traffic shaping, DoS attack prevention, port mirroring, DiffServ support, Weighted Round Robin (WRR) queuing, MAC address filtering, IPv6 support, firmware upgradable, Weighted Random Early Detection (WRED), sFlow, Rapid Spanning Tree Protocol (RSTP) support, VLAN Stacking, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), Network Admissions Control (NAC), Jumbo Frames support, Dynamic ARP Inspection (DAI), front to back airflow, Per-VLAN Spanning Tree Plus (PVST+), Equal-Cost Multipath (ECMP), STP Root Guard, LACP support, LLDP support, SNMP trap, DNS relay, Energy Efficient Ethernet, Dynamic VLAN Support (GVRP), loop prevention, enviromental monitoring, Ingress Layer 2 MAC Access Control Lists (ACLs), tagged VLAN, 4MB packet buffer |
Compliant Standards | IEEE 802.2, IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX |
RAM | 512 MB DDR SDRAM |
Flash Memory | 64 MB |
Built-in Devices | Led panel |
Status Indicators | Fail, status |
Interfaces | 24 x 1000Base-X SFP ¦ 1 x console RJ-45 management ¦ 2 x SFP+ ¦ 2 x network stack device SFP+ ¦ 1 x USB Type A |
Power Device | Internal power supply |
Installed Qty | 2 |
Power Redundancy | Yes |
Voltage Required | AC 120/230 V (50/60 Hz) |
MTBF | 430,000 hours |
Compliant Standards | FCC Class A certified, UL, TUV, cUL, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class A, AS/NZS 60950-1, ICES-003 Class A, RoHS, UL 60950-1, EN 60950-1, EN 60825-1, CAN/CSA C22.2 No. 60950-1-03, VCCI Class A |
OS Required | AlliedWare Plus |
Width | 44 cm |
Depth | 29 cm |
Height | 4.4 cm |
Weight | 5.6 kg |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 45 °C |
Humidity Range Operating | 5 - 90% (non-condensing) |
Min Storage Temperature | -25 °C |
Max Storage Temperature | 70 °C |
Humidity Range Storage | 5 - 95% (non-condensing) |
