Allied Telesis Industrial Ethernet Media Converter AT-IMC2000T/SC / Fibre media converter / GigE / 10Base-T, 100Base-TX, 1000Base-T, 1000Base-X, 100Base-X / RJ-45 / SC multi-mode / up to 550 m / 850 nm | AT-IMC2000T/SC-980
Please sign in so that we can notify you about a reply
Product Specification
| Device Type | Fibre media converter |
| Form Factor | External |
| Networking | Networking |
| Connectivity Technology | Wired |
| Cabling Type | 10Base-T, 100Base-TX, 1000Base-T, 1000Base-X, 100Base-X |
| Data Link Protocol | 100Mb LAN, GigE |
| Data Transfer Rate | 1 Gbps |
| Optical Wave Length | 850 nm |
| Max Transfer Distance | 550 m |
| Status Indicators | Link/activity |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 1 x Ethernet 1000Base-X - SC multi-mode female ¦ 1 x Ethernet 1000Base-T - RJ-45 female |
| Miscellaneous | Miscellaneous |
| Compliant Standards | FCC Class A certified, VCCI, EN55024, ICES, EN61000-3-2, EN61000-3-3, EN 55032 |
| Dimensions & Weight | Dimensions & Weight |
| Width | 11.1 cm |
| Depth | 9.6 cm |
| Height | 3.5 cm |
| Weight | 748 g |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 75 °C |
| Humidity Range Operating | 5 - 90% (non-condensing) |
Features - Allied Telesis - AT-IMC2000T/SC-980
Length
>50m
More Details
Product Code
425B207
EAN Code
0767035210544
Manufacturer
Allied Telesis
