Allied Telesis AT DMC100/LC / Fibre media converter / 100Mb LAN / 100Base-FX, 100Base-TX / RJ-45 / LC multi-mode / up to 2 km / 1310 nm | AT-DMC100/LC-50
Please sign in so that we can notify you about a reply
Product Features
- VLAN support
Many backbone switch products support the IEEE 802.1Q specification for VLANs that send data packets on the network. DMC series media converters are fully compatible with these packets, enabling them to be used in modern networks. - Smart MissingLink
The Smart MissingLink feature monitors network connections and provides notification when network segments fail, allowing network managers to quickly identify the source and location of failed segments and minimize downtime. - Simple installation
All Allied Telesis media converters feature auto MDI/MDI-X, allowing the converter to be connected to a PC, hub or switch with a simple UTP cable. The media converters also allow the installer to test the integrity of the fiber connection, by forcing the converters to communicate over the fiber cable. - Smart link restoration
Smart link restoration allows the devices, in cases of power failure, link loss or other interrupted service, to automatically restore the link without the need to restart/reset them.
Special Features
- VLAN support
- Simple installation
- Smart link restoration
Product Specification
| Device Type | Fibre media converter |
| Form Factor | Desktop |
| Localisation | Europe |
| Networking | Networking |
| Connectivity Technology | Wired |
| Cabling Type | 100Base-FX, 100Base-TX |
| Data Link Protocol | 100Mb LAN |
| Data Transfer Rate | 100 Mbps |
| Optical Wave Length | 1310 nm |
| Max Transfer Distance | 2 km |
| Status Indicators | Link/activity |
| Features | Auto-negotiation, VLAN support, auto-uplink (auto MDI/MDI-X), Smart Missing Link (SML), USB powered, Automatic Link Restoration |
| Compliant Standards | IEEE 802.1Q |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 1 x Ethernet 100Base-FX - LC multi-mode female x 2 ¦ 1 x Ethernet 100Base-TX - RJ-45 female |
| Miscellaneous | Miscellaneous |
| Cables Included | 1 x USB charge cable |
| Compliant Standards | FCC Class A certified, VCCI, C-Tick, CISPR 22 Class A, EN 61000-3-2, EN 61000-3-3, EN55024, RoHS, UL 60950-1, EN 60950-1, EN 55022 Class A |
| Power | Power |
| Power Device | External power adapter |
| Dimensions & Weight | Dimensions & Weight |
| Width | 3.18 cm |
| Depth | 9.14 cm |
| Height | 2.16 cm |
| Weight | 113 g |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 5 - 95% (non-condensing) |
Features - Allied Telesis - AT-DMC100/LC-50
More Details
Product Code
425B078
EAN Code
0767035209920
Manufacturer
Allied Telesis
