Antec VP PLUS Series VP650 PLUS / Power supply (internal) / ATX12V / EPS12V / 80 PLUS / AC 200-240 V / 650 Watt / active PFC / Europe | 0-761345-11672-5
Description
The VP650 PLUS is crafted for quality, performance and incredible value. This entry-level solution is rated from 500 W to 650 W, saving energy through its high efficiency of up to 85% efficient and is 80 PLUS Standard certified.
Antec VP PLUS Series VP650 PLUS / Power supply (internal) | 0-761345-11672-5
Special Features
- Continuous power - guaranteed 650 W continuous power from Antec
- 80 PLUS certified - up to 85% efficient, to reduce your electricity bill
- 120mm silent fan
- Thermal manager - an advanced low voltage fan control for optimal heat & noise management
- CircuitShield - full suite of industrial grade protections: UVP/OVP/SCP/OPP/NLO
- Multi PCI-E - 2 PCI-E connectors for multiple GPU support
Product Specification
| Device Type | Power supply - active Power Factor Correction (PFC) - internal |
| Specification Compliance | ATX12V / EPS12V |
| PSU Form Factor | ATX |
| Localisation | Europe |
| Input Voltage | AC 200-240 V |
| Input Voltage Margin | + 10% / - 10% |
| Frequency Required | 47 - 63 Hz |
| Power Output Connectors Details | 1 x power 24 pin ATX with detachable 4 pin section ¦ 1 x power 8 pin EPS12V with detachable 4 pin ATX12V section ¦ 2 x 8 pin PCI Express power with detachable 2 pin section ¦ 7 x 15 pin Serial ATA power ¦ 2 x 4 PIN internal power ¦ 1 x 4 PIN mini-power connector |
| Output Voltage | +3.3, +5, ±12 V |
| Power Capacity | 650 Watt |
| Output Current | +3.3V - 20 A ¦ +5V - 17 A ¦ +12V - 50 A ¦ -12V - 0.3 A ¦ +5VSB - 2.5 A |
| Efficiency | 85% |
| Power Factor (PF) | 0.9 |
| 80 PLUS Certification | 80 PLUS |
| Cooling System | 120 mm fan |
| Features | Thermal monitoring, over voltage protection, overpower protection, short-circuit protection, CircuitShield, no load operation protection, non-modular |
| Compliant Standards | TUV, CB, KC |
| Service & Support | Limited warranty - parts and labour - 3 years |
| Width | 15 cm |
| Depth | 14 cm |
| Height | 8.6 cm |
| Weight | 1.81 kg |
| Shipping Weight | 2.22 kg |
Features - Antec - 0-761345-11672-5
More Details
Product Code
04:316510
EAN Code
0761345116725
Manufacturer
Antec
