Extreme Networks AP5010 - Radio access point - Wi-Fi 6E - ZigBee, Thread, Bluetooth - 2.4 GHz, 5 GHz, 6 GHz - cloud-managed | AP5010-WW
Please sign in so that we can notify you about a reply
Product Specification
| Device Type | Radio access point |
| Ruggedized Design | Indoor |
| Width | 24.3 cm |
| Depth | 24.3 cm |
| Height | 3.8 cm |
| Weight | 1.32 kg |
| Localisation | Worldwide |
| Networking | |
| Form Factor | External |
| Connectivity Technology | Wireless |
| Data Transfer Rate | 10 Gbps |
| Line Coding Format | 256 QAM, OFDM, 1024 QAM, OFDMA, DSSS |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, ZigBee, IEEE 802.11ac, Thread, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.2 LE |
| Spread Spectrum Method | OFDM, DSSS, OFDMA |
| Cloud-Managed | Yes |
| Frequency Band | 2.4 GHz, 5 GHz, 6 GHz |
| Capacity | SSIDs per radio: 8 ¦ SSIDs total: 24 ¦ Users per radio: 512 ¦ Total users: 1536 |
| Features | Quality of Service (QoS), Trusted Platform Module (TPM), packet aggregation A-MPDU, packet aggregation A-MSDU, SU-MIMO technology, High-Throughput (HT) support, Energy-Efficient Ethernet (EEE), 4x4:4 MU-MIMO technology, security slot (Kensington security lock compatible), Cellular Coexistence Filter (CCF), Transmit Beamforming |
| Encryption Algorithm | WPA3 |
| Authentication Method | Radio Service Set ID (SSID) |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.3az, IEEE 802.11ac, IEEE 802.11ax, Wi-Fi CERTIFIED 6E |
| Aerial | |
| Antenna | Internal |
| Antenna Qty | 12 |
| Internet of Things (IoT) | |
| Internet of Things (IoT) Compatible | Yes |
| Communications Technology | Thread, Zigbee, Bluetooth 5.2 |
| Expansion / Connectivity | |
| Interfaces | 1 x 100M/1G/2.5/5 Gigabit Ethernet (PoE+) - RJ-45 ¦ 1 x 100M/1G/2.5 Gigabit Ethernet - RJ-45 ¦ 1 x USB 2.0 - Type A |
| Miscellaneous | |
| Included Accessories | Wall and ceiling mounting bracket |
| Compliant Standards | CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, IEC 60601-1-2, ICES-003 Class B, AS/NZS 60950-1, UL 2043, IEC 60950-1, UL 60950-1 Second Edition, EN 55011, REACH, EN 62311, EN 300.440, China RoHS, EN 300 328, RoHS 2011/65/EU, WEEE 2012/19/EU, EN 301 489-1, FCC CFR47 Part 15 B Class B, CAN/CSA C22.2 No. 60950-1 Second Edition, RSS-247, EN 301 489-1-17, EN 62479, EN 55032 Class B, Directive 2014/35/EU, Directive 2014/30/EU, EN 62368-1, IEC 62368-1, EN 301 893, CISPR 32 Class B, FCC Subpart C 15.247, FCC Subpart E 15.407, Directive 2014/53/EU, AS/NZS CISPR32:2013, SJ/T 11364-2014, EN 55035, CISPR 35, Taiwan BSMI RoHS, CNS 15663, EN 302 502, RoHS 2015/863/EU, UL/CUL 62368-1, SCIP, RSS-248, EN 303 687 |
| Power | |
| Power Over Ethernet (PoE) Supported | PoE+ |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - lifetime |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 0 - 95% (non-condensing) |
Features - extreme networks - AP5010-WW
More Details
Product Code
CD68830
EAN Code
0644728054992
Manufacturer
extreme networks
