ASRock X399 Phantom Gaming 6 / Motherboard / ATX / Socket TR4 / AMD X399 / USB 3.1 Gen 1, USB-C Gen2, USB 3.1 Gen 2 / Gigabit LAN, 2.5 Gigabit LAN / HD Audio (8-channel) | 90-MXB9B0-A0UAYZ
Description
The intelligent Phantom Gaming 6 LAN platform is built for maximum networking performance for the demanding requirements of home networking, content creators, online gamers and high-quality streaming media.
ASRock X399 Phantom Gaming 6 / Motherboard | 90-MXB9B0-A0UAYZ
Special Features
- Armor your VR machine
- RGB illumination
- Aluminum alloy heatsink
- Gold audio jacks
Product features
- Armor your VR machine
Prepare yourself well to enjoy the impressive world of virtual reality. Before that, you have to make sure everything is qualified, including hardware, software and drivers. Motherboard is the key to connect every critical components and ASRock's VR ready motherboards are definitely the one you're looking for. The premium quality is assured by rigorous testing during development. - RGB illumination
In addition to the built-in RGB illumination, it also features onboard RGB headers and an addressable RGB header that allow motherboard to be connected to compatible LED devices such as strip, CPU fans, coolers, chassis and so on. - Aluminum alloy heatsink
An extra-large aluminum alloy heatsink with heat pipe is added to effectively take away heat from the MOSFET, giving a more stable and long-lasting system. - Gold audio jacks
Everything will wear off in time, but gold looks better! Gold audio jack provides stable sound transmission.
Product Specification
| Product Type | Motherboard - ATX |
| Chipset Type | AMD X399 |
| Processor Socket | Socket TR4 |
| Max Processors Qty | 1 |
| Compatible Processors | Ryzen ThreadRipper |
| Max Size | 128 GB |
| Technology | DDR4 |
| Bus Clock | 2400 MHz, 2133 MHz, 2667 MHz, 2933 MHz (O.C.), 3200 MHz (O.C.), 3600 MHz (O.C.) |
| Supported RAM Integrity Check | Non-ECC, ECC |
| Registered or Buffered | Unbuffered |
| Features | Quad channel memory architecture |
| Type | HD Audio (8-channel) |
| Audio Codec | Realtek ALC1220 |
| Compliant Standards | High Definition Audio, Premium Blu-ray audio support, Sound Blaster Cinema 5 |
| Network Controller | Intel I219V / Dragon RTL8125AG |
| Network Interfaces | Gigabit Ethernet, 2.5 Gigabit Ethernet |
| Expansion Slots | 1 x CPU ¦ 8 x DIMM 288-pin ¦ 3 x PCIe 3.0 x16 (dual x16 mode; triple: x16, x16, x8 mode) ¦ 1 x M.2 socket (Key E) |
| Storage Interfaces | SATA-600 -connectors: 8 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 ¦ PCIe 3.0 -connectors: 2 x Ultra M.2 ¦ SATA-600 / PCIe 3.0 -connectors: 1 x Ultra M.2 |
| Interfaces | 1 x PS/2 keyboard / mouse ¦ 1 x LAN (2.5Gigabit Ethernet) ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x USB-C Gen2 ¦ 1 x USB 3.1 Gen 2 ¦ 8 x USB 3.1 Gen 1 ¦ 1 x audio line-out (rear) - mini-jack ¦ 1 x audio line-out (center/subwoofer) - mini-jack ¦ 1 x audio line-in - mini-jack ¦ 1 x audio line-out - mini-jack ¦ 1 x microphone - mini-jack ¦ 1 x TOSLINK |
| Internal Interfaces | 4 x USB 2.0 - header ¦ 4 x USB 3.1 Gen 1 - header ¦ 2 x audio - header |
| Power Connectors | 24-pin main power connector, 2 x 8-pin ATX12V connectors |
| BIOS Type | AMI |
| BIOS Features | JumperFree, SMBIOS 2.3 support, UEFI BIOS, ACPI 5.1 support |
| Hardware Monitoring | CPU core temperature, chassis temperature, CPU fan tachometer, chassis fan tachometer, system voltage, CPU core voltage |
| Sleep / Wake Up | Wake on LAN (WOL) |
| Hardware Features | Heat pipe chipset cooling, NVIDIA SLI Technology Support, 8 Phase Power Design, ASRock Instant Flash, NVIDIA 3-way SLI Technology Support, NVIDIA Quad SLI Technology Support, 15µ Gold Contact, AMD CrossFireX technology support, AMD Quad CrossFireX technology support, AMD 3-way CrossFireX technology support, Digi Power Design, ESD Protection, Gold Plated Audio Hardware, Energy Efficient Ethernet 802.3az, Preboot eXecution Environment (PXE), 8 Layer PCB, Clear CMOS Button, Direct Drive Technology, ASRock Full Spike Protection, ASRock APP Shop, ASRock Super Alloy, High Density Glass Fabric PCB, ASRock Full HD UEFI, ASRock Easy RAID Installer, Dr.MOS MOSFET, XXL Aluminum Alloy Heatsink, Nichicon Fine Gold Series Audio Capacitors, ASRock Live Update, ASRock Ultra M.2, Nichicon 12K Black Caps, Matte Black PCB, ASRock Steel Slots, TI NE5532 Premium Headset Amplifier, Premium 60A Power Choke, 120dB SNR DAC with Differential Amplifier, Pure Power-In, PCB Isolate Shielding, Combo Caps, M.2 heatsink |
| Included Accessories | I/O back plate, Wi-Fi bracket, ASRock SLI_HB_Bridge_2S Card, 4 x M.2 screws |
| Cables Included | 4 x Serial ATA cable |
| Software Included | Drivers & Utilities, Antivirus (Trial version), Google Chrome Browser, Google ChromeToolbar, ASRock Polychrome RGB, ASRock Phantom Gaming Tuning, ASRock Phantom Gaming LAN Software |
| Compliant Standards | Plug and Play, FCC, EuP Ready, ErP Ready |
| Width | 30.5 cm |
| Depth | 24.4 cm |
Features - Asrock - 90-MXB9B0-A0UAYZ
More Details
Product Code
03:214965
EAN Code
4717677337495
Manufacturer
Asrock
