ASUS ROG-STRIX-1000G / Power supply (internal) / ATX12V / 80 PLUS Gold / AC 100-240 V / 1000 Watt | 90YE00A5-B0NA00

90YE00A5-B0NA00
269.25
(320.41 inc. VAT)
Out of stock
Delivery
Payment options
Product Code03:156784 EAN Code4718017845571 ManufacturerAsus

Product Features

  • Let it sink in
    The integrated ROG heatsinks have 2x more volume than traditional designs, resulting in significantly lower temperatures inside ROG Strix Series PSUs. This extends the lifespan of components and allows 0 dB operation for a longer duration than standard designs. The heatsinks are so effective that fan noise stays whisper quiet, even under full load.
  • Axial-tech fan design
    Axial-tech fan design features a smaller fan hub that facilitates longer blades and a barrier ring that increases downward air pressure.
  • 2x longer lifespan
    Different bearing types have unique pros and cons.
  • Quiet intelligence
    An onboard controller brings the 135 mm fan to a standstill when thermal design power (TDP) is below 40%, letting you enjoy light gaming in relative silence. Above 40% TDP, the fans automatically start up again.
  • Heart of gold
    Japanese capacitors ensure efficient operation and have helped the Strix earn an 80 PLUS Gold certification. The increased efficiency also results in less heat, reducing noise and increasing reliability.
  • Cosmetic customization
    Getting everything looking right can be a challenging aspect of any setup. The ROG Strix Series PSUs aim to make your life a little easier with a convenient magnetic logo and stickers that help you reskin the visible side to your liking.
  • Fully modular cables
    Each model comes with fully modular 24-pin, 6+2-pin PCI-e, and 8-pin CPU cables that have embedded capacitors to reduce voltage ripple. And if you'd like to add a dash of color to your build, the CableMod coupon will set you on your way towards next-level customization.

Special Features

  • ROG heatsinks cover critical components, delivering lower temperatures and reduced noise
  • Axial-tech fan design features a smaller fan hub that facilitates longer blades and a barrier ring that increases downward air pressure
  • Dual ball fan bearings can last up to twice as long as sleeve bearing designs
  • 0 dB Technology lets you enjoy light gaming in relative silence
  • Cosmetic customization is enabled by a magnetic logo and stickers that help you reskin the visible side to your liking
  • Fully modular cables keep your rig neat and tidy

Product Specification

Device Type Power supply - internal
Specification Compliance ATX12V
PSU Form Factor ATX
Power Device Power Device
Input Voltage AC 100-240 V
Power Output Connectors Details 1 x power 24 pin ATX with detachable 4 pin section ¦ 2 x power 8 pin +12V with detachable 4 pin section ¦ 6 x 8 pin PCI Express power with detachable 2 pin section ¦ 8 x 15 pin Serial ATA power ¦ 6 x 4 PIN internal power
Output Voltage +3.3, +5, ±12 V
Power Capacity 1000 Watt
Output Current +3.3V - 25 A ¦ +5V - 25 A ¦ +12V - 83 A ¦ -12V - 0.3 A ¦ +5VSB - 3 A
Modular Cable Management Yes
80 PLUS Certification 80 PLUS Gold
Miscellaneous Miscellaneous
Included Accessories 2 x ROG badges, ROG logo magnet, 3 x ROG labels
Cooling System 135 mm fan
Features Overheat protection, over current protection, over voltage protection, overpower protection, short-circuit protection, dual ball bearing cooling fan, fully modular, ROG heatsink, Axial-tech fan design, 0db Technology
Compliant Standards RoHS
Manufacturer Warranty Manufacturer Warranty
Service & Support Limited warranty - 10 years
Dimensions & Weight Dimensions & Weight
Width 15 cm
Depth 16 cm
Height 8.6 cm
Weight 1.885 kg
Dimensions & Weight (Shipping) Dimensions & Weight (Shipping)
Shipping Weight 3.54 kg
