ASUS DSL-AC87VG / Wireless router / DSL modem / 4-port switch / GigE / WAN ports: 2 / 802.11a/b/g/n/ac / Dual Band / VoIP phone adapter (DECT) | 90IG02M0-BM3H00
ASUS DSL-AC87VG / Wireless router / DSL modem / 4-port switch / GigE / WAN ports: 2 / 802.11a/b/g/n/ac / Dual Band / VoIP phone adapter (DECT) | 90IG02M0-BM3H00
Description With a dual-band four-transmit, four-receive (4T4R) antenna design, both Wi-Fi range and signal stability improve dramatically. AiRadar further focuses Wi-Fi signal on your devices, making your Wi-Fi faster, clearer and stronger. DSL-AC87VG has multiple ways to connect to the internet, with a choice of DSL, Ethernet or 3G/4G LTE . You can use DSL-AC87VG as a DSL modem Wi-Fi router or a standalone Wi-Fi router according to your needs. And with the ability to switch instantly between connections if one fails (and switch back again when it's fixed), it's perfect for reliable, always-on internet connectivity.The DSL-AC87VG offers dual CPU performance and flexibility. Its twin processors each optimize wired and wireless connections. By separating wired VDSL/ADSL and Wi-Fi networking into two compute modules with their own dedicated processing power, the DSL-AC87VG achieves maximum performance for both connection types with no compromises.DSL-AC87VG has advanced VoIP capabilities that allow it to be used as a complete home internet telephony system. Users can register DSL-AC87VG with up to 10 SIP-compatible VoIP accounts, and connect standard analog telephones or fax machines to the two standard RJ-11 telephony ports. Up to five cordless DECT phones can also be connected to the built-in DECT base station . Any GAP-compatible DECT phone can be connected, and DSL -AC87VG also supports the Eco-DECT energy-saving standard . Special Features
Product features
|
Product Specification
Device Type | Wireless router - 4-port switch (integrated) |
Enclosure Type | Desktop |
Connectivity Technology | Wireless, wired |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
Frequency Band | 2.4 GHz / 5 GHz |
Data Transfer Rate | 2334 Mbps |
Network / Transport Protocol | PPTP, L2TP, FTP, DHCP |
Encryption Algorithm | WPA-PSK, WPA2-PSK |
Features | NAT support, dynamic DNS server, print server, IPv6 support, firmware upgradable, download client, Quality of Service (QoS), built-in DECT phone base station, Wi-Fi Protected Setup (WPS), WAN failover, DHCP server, FTP server, reset button, IPv4 support, 3G/4G USB Dongle Support, ASUS AiRadar, VPN Server, ASUSWRT, VPN client |
Compliant Standards | IEEE 802.3u, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11i, IEEE 802.11e, IEEE 802.11n, IEEE 802.11ac, ETSI |
RAM | 512 MB DDR3 SDRAM |
Flash Memory | 256 MB |
Status Indicators | Power, phone, WLAN, WAN, LAN, USB, ADSL, Internet, DECT |
Type | DSL modem |
Digital Signaling Protocol | ADSL, SIP, ADSL2, ADSL2+, VDSL2, Vplus 35b |
VoIP Functionality | VoIP phone adapter (DECT) |
VoIP Protocols | SIP |
Telephony Interfaces | DECT |
Interfaces | LAN: 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ USB 2.0: 1 x ¦ WAN: 1 x VDSL2 / ADSL2+ - RJ-45 ¦ WAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ Phone line: 2 x RJ-11 ¦ USB 3.0: 1 x ¦ TAE: 2 x |
Aerial | External detachable |
Antenna Qty | 4 |
Power Device | External power adapter |
Voltage Required | AC 120/230 V (50/60 Hz) |
Cables Included | 1 x network cable ¦ 1 x modem cable |
OS Required | Apple MacOS X 10.4, Apple MacOS X 10.6, Apple MacOS X 10.5, Apple MacOS X 10.7 Lion, Apple MacOS X 10.8, Microsoft Windows XP/ 7 / 8 / 8.1 / 10 |
Width | 31.7 cm |
Depth | 8.7 cm |
Height | 19.3 cm |
Weight | 1.05 kg |
Service & Support | Limited warranty - 3 years |
