Axis T8508 PoE+ Network Switch / Switch / Managed / 8 x 10/100/1000 (PoE+) + 2 x combo Gigabit SFP (uplink) / desktop, rack-mountable / PoE+ (130 W) | 01191-002
Description
AXIS T8508 PoE+ Network Switch is an easy-to-install network switch optimized for surveillance solutions, that comes with a unique web graphic user interface with topology for easy overview and management of all devices in the system.
Axis T8508 PoE+ Network Switch / Switch | 01191-002
Special Features
- Fan-less for noise sensitive installations
- Optimized for surveillance solutions
- Easy installation and configuration
- Unique web graphic user interface
Product Specification
| Device Type | Switch - 8 ports - Managed |
| Enclosure Type | Desktop, rack-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 8 x 10/100/1000 (PoE+) + 2 x combo Gigabit SFP (uplink) |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 130 W |
| Performance | Throughput: 14.9 Mpps ¦ Switching capacity: 20 Gbps |
| MAC Address Table Size | 8K entries |
| Jumbo Frame Support | 9216 bytes |
| Routing Protocol | IGMP |
| Remote Management Protocol | SNMP 1, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, SMTP |
| Authentication Method | Secure Shell (SSH) |
| Features | DHCP support, ARP support, VLAN support, IP address filtering, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), DHCP server, LLDP support, Network Access Control (NAC), 802.1x authentication, metal housing, administrator's password, Bridge protocol data unit (BPDU), Internet Control Message Protocol (ICMP), 6KV Surge protection, Network Timing Protocol (NTP), LLDP-MED, User Datagram Protocol (UDP), HTTPS encryption |
| Compliant Standards | IEEE 802.1x, IEEE 802.1ab (LLDP), IEEE 802.3at, UPnP |
| Interfaces | 8 x 1000Base-T RJ-45 PoE+ - 30 W ¦ 2 x 1000Base-T RJ-45 uplink ¦ 2 x 1000Base-X SFP uplink |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Colour | Black |
| Included Accessories | 4 rubber feet, drill template |
| Compliant Standards | SASO, EN55024, JATE, ICES-003 Class A, FCC Part 15 B Class A, VCCI Class A, EAC, AS/NZS CISPR 32 Class A, EN 55032 Class A, IEC/EN/UL 60950-1 |
| Software Included | Axis Camera Management |
| Width | 22 cm |
| Depth | 24.2 cm |
| Height | 4.4 cm |
| Weight | 2.1 kg |
| Service & Support | Limited warranty - 3 years |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Min Storage Temperature | -10 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 5 - 95% (non-condensing) |
