be quiet! System Power B9 600W bulk / Power supply (internal) / ATX12V 2.4/ EPS12V 2.92 / 80 PLUS Bronze / AC 200-240 V / 600 Watt / active PFC / black | BN209
Description
be quiet! System Power B9 is specially designed to suit the needs of price-conscious PC builders.
be quiet! System Power B9 600W bulk / Power supply (internal) | BN209
Special Features
- Cost effective and efficient handling
- Very quiet operation
- A complete range of safety features
Product features
- Cost effective and efficient handling
System Power B9 was designed to meet the needs of system integrators. The PSU is very cost-efficient and ensures quick and easy handling to streamline the production of pre-configured PCs. - Very quiet operation
System Power B9 is equipped with a temperature-controlled fan. This ensures its operation produces the low noise that be quiet! is famous for. - A complete range of safety features
Top component protection with a full suite of safety functions provide the ultimate in secure operation.
Product Specification
| Device Type | Power supply - active Power Factor Correction (PFC) - internal |
| Specification Compliance | ATX12V 2.4/ EPS12V 2.92 |
| PSU Form Factor | ATX |
| Colour | Black |
| Input Voltage | AC 200-240 V |
| Frequency Required | 50 Hz |
| Power Output Connectors Details | 1 x power 24 pin ATX with detachable 4 pin section ¦ 1 x power 8 pin EPS12V with detachable 4 pin ATX12V section ¦ 2 x 8 pin PCI Express power with detachable 2 pin section ¦ 2 x 4 PIN internal power ¦ 6 x 15 pin Serial ATA power |
| Output Voltage | +3.3, +5, ±12 V |
| Power Capacity | 600 Watt |
| Output Current | +3.3V - 24 A ¦ +5V - 15 A ¦ +12V1 - 28 A ¦ +12V2 - 22 A ¦ -12V - 0.3 A ¦ +5VSB - 3 A |
| Efficiency | 87% at 20% Load, 86% at 100% Load, 89% at 50% Load |
| Power Factor (PF) | 0.95 |
| 80 PLUS Certification | 80 PLUS Bronze |
| Cables Included | Power cable 1.5 m |
| MTBF | 100,000 hours |
| Cooling System | 120 mm fan |
| Features | Sleeved cables, overheat protection, over current protection, over voltage protection, overload protection, undervoltage protection, dual 12V rails, short-circuit protection, temperature controlled fan, DC-DC technology, sleeve bearing cooling fan |
| Compliant Standards | TUV, CB, RoHS, WEEE, ERP, RCM, CU |
| ENERGY STAR | Yes |
| Service & Support | Limited warranty - 3 years |
| Max Operating Temperature | 40 °C |
| Sound Emission | 31.2 dBA |
| Width | 15 cm |
| Depth | 14 cm |
| Height | 8.6 cm |
| Weight | 1.98 kg |
Features - be quiet! - BN209
More Details
Product Code
T380701
EAN Code
4260052186015
Manufacturer
be quiet!
