Chieftec Core Series BBS-600S - Power supply (internal) - ATX12V 2.3/ EPS12V/ PS/2 - 80 PLUS Gold - AC 100-240 V - 600 Watt - active PFC | BBS-600S
Please sign in so that we can notify you about a reply
Special Fetures
- 80 PLUS Gold efficiency
- Compact size with only 140mm depth
- 600W power output
- Motherboard, CPU and PCI-E cable lengths of 650mm
Product Specification
| Device Type | Power supply - active Power Factor Correction (PFC) - internal |
| Specification Compliance | ATX12V 2.3/ EPS12V/ PS/2 |
| PSU Form Factor | ATX |
| Power Device | |
| Input Voltage | AC 100-240 V |
| Frequency Required | 47 - 63 Hz |
| Power Output Connectors Details | 1 x power 24 pin ATX ¦ 1 x power 8 pin EPS12V with detachable 4 pin ATX12V section ¦ 2 x 8 pin PCI Express power with detachable 2 pin section ¦ 3 x 4 PIN internal power ¦ 6 x 15 pin Serial ATA power ¦ 1 x 4 PIN mini-power connector |
| Output Voltage | +3.3, +5, ±12 V |
| Power Capacity | 600 Watt |
| Output Current | +5V - 20 A ¦ +3.3V - 20 A ¦ +12V - 49 A ¦ +5VSB - 2.5 A ¦ -12V - 0.3 A |
| Power Factor (PF) | 0.9 |
| 80 PLUS Certification | 80 PLUS Gold |
| Miscellaneous | |
| Cooling System | 120 mm fan |
| Features | Over voltage protection, overpower protection, short-circuit protection, non-modular |
| Compliant Standards | CB, RoHS, ErP Ready, EAC, TUV Rheinland |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Dimensions & Weight | |
| Width | 15 cm |
| Depth | 14 cm |
| Height | 8.6 cm |
| Weight | 1.67 kg |
| Dimensions & Weight (Shipping) | |
| Shipping Weight | 2.08 kg |
Features - Chieftec - BBS-600S
More Details
Product Code
07:233791
EAN Code
0753263076137
Manufacturer
Chieftec
