Chieftec Smart Series GPS-750C / Power supply (internal) / ATX12V 2.3 / 80 PLUS Gold / AC 100-240 V / 750 Watt / active PFC / black | GPS-750C
|
Description Today, system integrators do not only require for their PC assembly line, a durable and quality-promising chassis but a highly reliable power supply source as well. Chieftec's power supply units of the Smart Series fulfill these and more requirements. |
Product Specification
| Device Type | Power supply - active Power Factor Correction (PFC) - internal |
| Specification Compliance | ATX12V 2.3 |
| Colour | Black |
| Input Voltage | AC 100-240 V |
| Frequency Required | 47 - 63 Hz |
| Power Output Connectors Details | 1 x power 24 pin ATX with detachable 4 pin section ¦ 1 x power 8 pin EPS12V with detachable 4 pin ATX12V section ¦ 6 x 15 pin Serial ATA power ¦ 3 x 4 PIN internal power ¦ 4 x 8 pin PCI Express power with detachable 2 pin section ¦ 1 x power 4 pin ATX12V connector |
| Output Voltage | +3.3, +5, ±12 V |
| Power Capacity | 750 Watt |
| Output Current | +3.3V - 22 A ¦ +5V - 22 A ¦ +12V1 - 62 A ¦ -12V - 0.3 A ¦ +5VSB - 2.5 A |
| Efficiency | 90% |
| Power Factor (PF) | 0.9 |
| 80 PLUS Certification | 80 PLUS Gold |
| Cooling System | 140 mm fan |
| Features | Sleeved cables, overheat protection, over current protection, over voltage protection, SLI ready, overload protection, undervoltage protection, short-circuit protection, single 12V rail, CrossFireX ready, fan speed control, Intel 4th-gen CPU (Haswell) compatible, Silent Cooling |
| Compliant Standards | TUV, CB, RoHS, ERP |
| Service & Support | Limited warranty - 3 years |
| Width | 15 cm |
| Depth | 16 cm |
| Height | 8.7 cm |
Features - Chieftec - GPS-750C
More Details
Product Code
03:526796
EAN Code
4710713233584
Manufacturer
Chieftec
