Power supply Chieftec TASK Series TPS-700S / ATX12V 2.3/ EPS12V/ PS/2 / 80 PLUS Bronze / AC 100-240 V / 700 Watt / active PFC | TPS-700S
Please sign in so that we can notify you about a reply
Chieftec TASK Series TPS-700S / Power supply (internal) / ATX12V 2.3/ EPS12V/ PS/2 / 80 PLUS Bronze / AC 100-240 V / 700 Watt / active PFC | TPS-700S
Description
The Chieftec TASK Series PSUs are true to their name, and take on any task they are required for without any trouble. These power supplies will also serve excellently for builds inside larger cases.
Product Specification
| Device Type | Power supply - active Power Factor Correction (PFC) - internal |
| Specification Compliance | ATX12V 2.3/ EPS12V/ PS/2 |
| PSU Form Factor | ATX |
| Input Voltage | AC 100-240 V |
| Frequency Required | 47 - 63 Hz |
| Power Output Connectors Details | 1 x power 24 pin ATX with detachable 4 pin section ¦ 1 x power 8 pin EPS12V with detachable 4 pin ATX12V section ¦ 6 x 15 pin Serial ATA power ¦ 2 x 8 pin PCI Express power with detachable 2 pin section ¦ 3 x 4 PIN internal power |
| Output Voltage | +3.3, +5, ±12 V |
| Power Capacity | 700 Watt |
| Output Current | +5V - 17 A ¦ +3.3V - 19 A ¦ +12V1 - 54 A ¦ -12V - 0.3 A ¦ +5VSB - 2.5 A |
| Power Factor (PF) | 0.9 |
| 80 PLUS Certification | 80 PLUS Bronze |
| Cooling System | 120 mm fan |
| Features | Overheat protection, over voltage protection, overpower protection, undervoltage protection, short-circuit protection, Automatic Fanspeed Control (AFC) |
| Compliant Standards | CB, FCC, RoHS, WEEE, ERP, EAC, Interseroh, TUV Rheinland |
| Service & Support | Limited warranty - 2 years |
| Weight | 1.74 kg |
| Shipping Weight | 2.15 kg |
Features - Chieftec - TPS-700S
More Details
Product Code
07:135280
EAN Code
0753263076502
Manufacturer
Chieftec
