Cisco AIR-ANT2524DG-R= Cisco Aironet Dual-Band Dipole Antenna 2 dBi, 4 dBi - grey for Aironet 3602E, AIR-ANT2524DG-R=

Cisco Aironet Dual-Band Dipole Antenna 2 dBi, 4 dBi - grey for Aironet 3602E, AIR-ANT2524DG-R=

The Cisco Aironet high-performance, dual-band dipole antenna. The antenna operates in both the 2.4-GHz and 5-GHz frequency bands and is designed for use with Cisco Aironet 2.4-GHz and 5-GHz radio products that have dual-band reverse-polarity TNC RP-TNC antenna ports. The antenna has a nominal gain of 2 dBi in the 2.4-GHz frequency band and 4 dBi in the 5-GHz frequency band.

Feature list

Antenna gain level max: 4 dBi
Frequency band: 2.4/5 GHz
Antenna type: omni-directional
Impedance: 50 Ω
Antenna connector type: RP-TNC
Voltage Standing Wave Ratio VSWR: 2:1
Frequency range: 2.4 - 2.5GHz, 5.15 - 5.85GHz
Gender type: male
Antenna gain 2.4 GHz: 2 dBi
Antenna gain 5 GHz: 4 dBi
Purpose: indoor
Horizontal beam width 2.4 GHz: 63 °
Horizontal beam width 5 GHz: 39 °
Operating temperature range T-T: -20 - 60 °C
Storage temperature range T-T: -40 - 85 °C
Weight: 38.5 g
Width: 21 mm
Depth: 168.5 mm
Colour of product: White

Cisco Aironet Dual-Band Dipole Antenna 2 dBi, 4 dBi - grey for Aironet 3602E, AIR-ANT2524DG-R=
