Cisco Catalyst Rugged Series IR8340 - Router - 14-port switch - GigE - WAN ports: 2 - rack-mountable | IR8340-K9

Cisco Catalyst Rugged Series IR8340 - Router - 14-por | IR8340-K9

Description
Features
Reviews

Product Specification

Device Type	Router - 14-port switch (integrated)
Enclosure Type	Rack-mountable - 2U
Connectivity Technology	Wired
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Performance	PoE power budget: 120 Watt
Capacity	IPSec tunnels: 20
Network / Transport Protocol	TCP/IP, L2TP, RSVP, NTP, IPSec, FTP, DHCP, DNS, RTP, HTTP, HTTPs, cRTP, Telnet
Routing Protocol	RIP-1, RIP-2, BGP, EIGRP, IGMPv2, HSRP, IGMP, VRRP, NHRP, OSPFv2, IGMPv3, EIGRP for IPv6, GRE, OSPFv3, Multiprotocol BGP, static IPv6 routing, policy-based routing (PBR), RIPng, Bidirectional Forwarding Detection (BFD), RSVP, MSTP, RSTP, STP, MGRE
Remote Management Protocol	SNMP, Telnet, HTTP, HTTPS, SSH, CLI, SCP, NETCONF, NTP, DHCP, RSTP, OMP
Encryption Algorithm	SSL, TLS, SHA-1, FIPS 140-2, PKI, 256-bit AES, IKEv2, SHA-2, DTLS, 2048-bit RSA, 256-bit AES-CBC, ESP, ECDSA 256-bit, ECDSA 384-bit, IKEv1, SHA-384, SHA-512, HMAC
Features	NAT support, VPN support, IGMP snooping, DiffServ support, Low-latency queuing (LLQ), Class-Based Weighted Fair Queuing (CBWFQ), Weighted Fair Queuing (WFQ), Weighted Random Early Detection (WRED), Per-VLAN Spanning Tree (PVST), Port Aggregation Protocol (PAgP) support, Quality of Service (QoS), Dynamic Multipoint VPN (DMVPN), DHCP server, Virtual Route Forwarding-Lite (VRF-Lite), LACP support, LLDP support, DHCP relay, Remote Switch Port Analyzer (RSPAN), Management Information Base (MIB), Virtual Routing and Forwarding (VRF), Forward Error Correction (FEC), Class of Service (CoS), IPFIX, Flexible NetFlow (FNF), 802.1x authentication, Precision Time Protocol (PTP), DiffServ Code Point (DSCP) support, MACsec support, Resilient Ethernet Protocol (REP), Parallel Redundancy Protocol (PRP), Control plane protection (CoPP), TrustSec support, Authentication, Authorization and Accounting (AAA), IGMP querier, Root Guard, Loop Guard, DNS client, High-speed Self Recovery (HSR), Synchronous Ethernet (SyncE), secure boot, Switched Port Analyzer (SPAN), Security Group Tag (SGT) caching, VLAN Trunking Protocol (VTP) v.3, Network-Based Application Recognition (NBAR), BPDU Guard, VLAN trunking, VLAN Trunking Protocol (VTP) v.2, Class-Based Traffic Shaping (CBTS), Class-Based Traffic Policing (CBTP), Class-Based Weighted Random Early Detection (CBWRED), Free Range Routing (FRR), Cisco Discovery Protocol (CDP), Trusted Anchor Module (TAM), Application Aware Routing (AAR), Secure Unique Device Identification (SUDI), Unidirectional Link Detection (UDLD), FirstNet ready, loop protection, Group Encrypted Transport (GETVPN)
Compliant Standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ae, IEEE 802.1ab (LLDP), VCCI, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, CISPR 22, EN50082-1, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, EN 61000-4-5, EN 61000-6-2, EN 61000-4-11, EN 61000-6-4, FCC CFR47 Part 15 B, EN 50121-4, IEC 62236-4, CNS 13438, EN 301 489, IEC 61850-3, IEEE 1613, EN 300 386, USGv6, EN 50155, IEC 62368-1, NOM-019-SCFI, ICES-003 issue 6, CISPR 32, EN 55032, IEC/EN 60950-1, EN 55035, IEC 61000-6-4, IEEE 1588v2, EN 50125-3, UL/CSA 61010-2-201, KN 61000-3-2, KN 61000-3-3, AS/NZS CISPR 32, IEC/EN 62368-1, UL/CSA 62368-1, IEC 61000-4-12, KS C 9832, IEC 60255-21-3 Class 1, IEC 61000-6-5, EN 50153
Processor	Intel
RAM	8 GB
Flash Memory	16 GB
Built-in Devices	SD card reader
Status Indicators	Status
Expansion / Connectivity
Interfaces	LAN: 4 x 1000Base-T (UPOE) - RJ-45 ¦ LAN: 4 x 1000Base-T/1000Base-X - RJ-45/SFP ¦ LAN: 4 x 1000Base-X - SFP (mini-GBIC) ¦ WAN: 2 x 1000Base-T/1000Base-X - RJ-45/SFP ¦ Console: 1 x RJ-45 ¦ 1 x SuperSpeed USB 3.0 ¦ Alarm: 1 x RJ-45
Expansion Slots	2 (total) / 2 (free) x NIM ¦ 2 (total) / 2 (free) x Pluggable Interface Module (PIM)
Miscellaneous
MTBF	239,274 hours
Dimensions & Weight
Width	43.82 cm
Depth	38.1 cm
Height	8.89 cm
Manufacturer Warranty
Service & Support	Limited warranty - advance hardware replacement - 1 year - response time: 10 days
Environmental Parameters
Min Operating Temperature	-40 °C
Max Operating Temperature	60 °C
Humidity Range Operating	5 - 95% (non-condensing)
