Cooler Master MasterBox TD500 ARGB / Tower / extended ATX / no power supply (ATX) / black / USB/Audio | MCB-D500D-KANN-S01
Cooler Master MasterBox TD500 ARGB / Tower / extended ATX / no power supply (ATX) / black / USB/Audio | MCB-D500D-KANN-S01
Description
The MasterBox TD500 ARGB approaches PC lighting in a completely different perspective. The front and side panels feature a crystalline structure, designed to uniquely interact with hardware lighting depending on the viewing angle. To make the most of the panels’ structure, three ARGB fans come pre-installed behind the front panel. To avoid interrupting the front panel design, seamless implementation of mesh ventilation makes up the entire perimeter of the panel. Hidden by the front bezel, considerable airflow is provided to the system almost completely out of view.
Cooler Master MasterBox TD500 ARGB / Tower | MCB-D500D-KANN-S01
Special Features
- Crystalline panels
- Concealed ventilation
- ARGB lighting system
- Edge-to-edge side panels
Product features
- Crystalline panels
The front and side panels feature a three-dimensional, crystalline design that refracts light differently depending on the viewing angle. - Concealed ventilation
The entire perimeter of the front panel is ventilated with mesh, placed behind the front bezel and hidden out of view. - ARGB lighting system
Three pre-installed ARGB fans can be managed by either the motherboard or an included controller, connected by the included splitter, to create a comprehensive ARGB lighting system. - Edge-to-edge side panels
Gaming hardware, cooling components, and the pure pride of the builder is shown in panoramic view through an edge-to-edge acrylic side panel.
Product Specification
Form Factor | Tower |
Max Mainboard Size | Extended ATX |
Supported Motherboards | ATX, microATX, Mini-ITX, Extended ATX |
Specification Compliance | ATX |
Internal Bays Qty | 6 |
Product Material | Plastic, steel, acrylic |
Colour | Black |
Cooling System | Front: 120 mm fan x 3 / ARGB fan, 2 x 140 mm fan supported ¦ Rear: 120 mm fan x 1 / black ¦ Top: 120 mm fan mount x 3 / 2 x 140 mm fan supported |
CPU Cooler Max Height | 165 mm |
Video Card Max Length | 410 mm |
Power Supply Max Length | 180 mm |
System Cabinet Features | Top panel dust filter, front dust filter, acrylic side panel, bottom dust filter, supports 120/140/240/280/360 mm radiator in front panel, supports 120/240/360 mm radiator in top, supports 120 mm radiator in rear panel, ARGB fans |
Expansion Bays | 2 (total) / 2 (free) x internal - 2.5" / 3.5" shared ¦ 4 (total) / 4 (free) x internal - 2.5" |
Expansion Slots | 7 |
Interfaces | 2 x USB 3.2 Gen 1 ¦ 1 x headphones - mini-jack ¦ 1 x microphone - mini-jack |
Included Accessories | ARGB controller, ARGB LED splitter cable (3-way) |
Power Device | No power supply |
Width | 21.7 cm |
Depth | 49.3 cm |
Height | 46.9 cm |
Weight | 5.75 kg |
Shipping Width | 29 cm |
Shipping Depth | 52.7 cm |
Shipping Height | 57 cm |
Shipping Weight | 7.07 kg |
Service & Support | Limited warranty - 2 years |
