Cooler Master MasterBox 520 MESH - Mid tower - extended ATX - windowed side panel (tempered glass) - no power supply (ATX) - black - USB/Audio | MB520-KGNN-S00
Please sign in so that we can notify you about a reply
Product Features
- Fine mesh performance front panel
Large mesh intakes offer unrestricted airflow and stellar thermals for demanding systems. - Three CF120 ARGB fans included
Pre-installed CF120 ARB fans provide ample airflow, ensuring low temperatures, high performance, and eye-catching aesthetics during even the most intense gaming sessions. - Removable top panel
The top panel is entirely removable for improved access and easy installation of cooling solutions such as fans and radiators. - Screwless and tool-free TG side panel
The tempered glass side panel is secured with pins for easy removal, facilitating quick, easy installation. - Versatile cooling options
Supports up to seven 120 mm fans and dual 360 mm radiators on the top and front panel. - Removable hod cage
The HDD cage is completely removable for improved access during assembly and system upgrades. - ARGB/fan hub included
The included controller allows users to manage systems lighting independently from the hardware configuration and provides the user with 4 additional fan headers in case of need. - Upgraded removable dust filter bracket
The bottom dust filter bracket is robust and locked sturdily in place during travel, remaining easy to remove for cleaning purposes. - Rich connectivity
The I/O panel comes with a USB 3.2 (Gen 2) Type-C port, a USB 3.2 (Gen 1) Type-A port, and one 3.5 mm (audio + mic) headset jack. - Breathable power supply shroud
The ventilated PSU cover supports both active and passive cooled PUs installed in multiple orientations. - Hardware compatibility
MasterBox 520 Mesh is natively compatible with ITX, M-ATX and ATX motherboards. E-ATX motherboards, such as SSI-CEB models, are compatible with dimensions up to 12" x 10.7".
Special Fetures
- Fine mesh performance front panel
- Three CF120 ARGB fans included
- Removable top panel
- Screwless and tool-free TG side panel
- Versatile cooling options
- Removable hod cage
- ARGB/fan hub included
- Upgraded removable dust filter bracket
- Rich connectivity
- Breathable power supply shroud
- Hardware compatibility
Product Specification
| Form Factor | Mid tower |
| Windowed Side Panel | Yes |
| Windowed Side Panel Material | Tempered glass |
| Max Mainboard Size | Extended ATX |
| Supported Motherboards | ATX, microATX, Mini-ITX, Extended ATX, SSI CEB |
| Internal Bays Qty | 5 |
| Product Material | Steel, ABS plastic, mesh |
| Colour | Black |
| Cooling System | Front: 120 mm fan x 3 / ARGB fan, 2 x 140 mm fan supported ¦ Rear: 120 mm fan mount x 1 ¦ Top: 120 mm fan mount x 3 / 2 x 140 mm fan supported |
| CPU Cooler Max Height | 165 mm |
| Video Card Max Length | 410 mm |
| Power Supply Max Length | 200 mm |
| System Cabinet Features | Top panel dust filter, front dust filter, removable HDD cage, bottom dust filter, supports 120/140/240/280/360 mm radiator in front panel, supports 120/140/240/280/360 mm radiator in top, supports 120 mm radiator in rear panel, ARGB fans |
| Expansion / Connectivity | |
| Expansion Bays | 2 (total) / 2 (free) x internal - 3.5" ¦ 3 (total) / 3 (free) x internal - 2.5" |
| Expansion Slots | 7 |
| Interfaces | 1 x USB 3.2 Gen 1 ¦ 1 x USB-C 3.2 Gen 2 ¦ 1 x headphone/microphone - mini-jack |
| Miscellaneous | |
| Included Accessories | ARGB controller |
| Power | |
| Power Device | No power supply |
| Specification Compliance | ATX |
| Max Supported Qty | 1 |
| Dimensions & Weight | |
| Width | 21 cm |
| Depth | 50.2 cm |
| Height | 49.8 cm |
| Weight | 7.13 kg |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 28.5 cm |
| Shipping Depth | 55.3 cm |
| Shipping Height | 57.4 cm |
| Shipping Weight | 9.01 kg |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
Features - Cooler Master - MB520-KGNN-S00
More Details
Product Code
04:420429
EAN Code
4719512126486
Manufacturer
Cooler Master
