D-Link DGS 1100-08V2 / Switch / smart / 8 x 10/100/1000 / desktop / AC 100/240 V | DGS-1100-08V2/E
Please sign in so that we can notify you about a reply
D-Link DGS 1100-08V2 / Switch / smart / 8 x 10/100/1000 / desktop / AC 100/240 V | DGS-1100-08V2/E
Product Specification
| Device Type | Switch - 8 ports - smart |
| Enclosure Type | Desktop |
| Subtype | Gigabit Ethernet |
| Ports | 8 x 10/100/1000 |
| Performance | Switching capacity: 16 Gbps ¦ Forwarding performance: 11.9 Mpps |
| Capacity | VLAN groups: 128 ¦ VLAN IDs: 4094 ¦ IGMP groups: 128 |
| MAC Address Table Size | 4K entries |
| Routing Protocol | IGMPv2, IGMP, IGMPv3 |
| Remote Management Protocol | SNMP 2, ICMP |
| Encryption Algorithm | SSL |
| Features | Flow control, auto-negotiation, BOOTP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, DoS attack prevention, port mirroring, Broadcast Storm Control, full duplex mode, Multicast Storm Control, Unicast Storm Control, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Quality of Service (QoS), Cable Diagnostics Function, bandwidth control, fanless, LLDP support, Port Security, DHCP client, tagged VLAN, DiffServ Code Point (DSCP) support, 1.5MB packet buffer, IGMP querier, Voice VLAN, VLAN management, VLAN group, Energy-Efficient Ethernet (EEE), Weighted Round Robin (WRR), Head-of-line (HOL) Blocking Prevention, loopback detection, port-based VLAN, port-based QoS, Unknown Storm Control, DNA support, Asymmetric VLAN |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1ab (LLDP), IEEE 802.3az |
| Flash Memory | 2 MB |
| Status Indicators | Power, status, link/activity/speed |
| Interfaces | 8 x 1000Base-T RJ-45 |
| Power Device | External power adapter |
| Voltage Required | AC 100/240 V (50/60 Hz) |
| Power Consumption Operational | 4.94 Watt |
| Power Consumption Stand by | 1.93 Watt |
| MTBF | 1,456,992 hours |
| Compliant Standards | FCC Class A certified, C-Tick, BSMI, cUL, CB, CCC, RoHS, LVD, VCCI Class A |
| Software Included | D-Link Network Assistant |
| Width | 14.5 cm |
| Depth | 8.2 cm |
| Height | 2.8 cm |
| Weight | 340 g |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 0 - 90% (non-condensing) |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 0 - 95% (non-condensing) |
Features - D-Link - DGS-1100-08V2/E
General
8-Port
More Details
Product Code
04:361842
EAN Code
0790069453410
Manufacturer
D-Link
