Datalogic Gryphon I GD4520 / Barcode scanner / handheld / 2D imager / decoded / USB | GD4520-BK-B-USB

Datalogic Gryphon I GD4520 Barcode GD4520-BK-B-USB

Description
Features

Datalogic Gryphon I GD4520 / Barcode scanner / handheld / 2D imager / decoded / USB | GD4520-BK-B-USB

Description

The Gryphon 4500 series is a premium range of handheld scanners from Datalogic for general purpose applications. Designed with people in mind, the Gryphon I GD4500 imager stands out with an elegant and trendy design, unchallenged ergonomics and features outstanding performance.

Datalogic Gryphon I GD4520 / Barcode scanner / handheld / 2D imager | GD4520-BK-B-USB

Special Features

Advanced technologies for today's POS
Simple to use and deploy

Product features

Advanced technologies for today's POS
Perfect for both handheld and presentation reading, the Gryphon I GD4500 imager exploits Datalogic motion-sensing technology which detects the natural actions of the operator to automatically switch the scanner into the desired scanning mode. This technology works with or without the use of a stand, offering more operational choices.
Simple to use and deploy
The Gryphon I GD4500 omnidirectional imager provides snappy reading performance on all common 1D and 2D codes as well as postal, stacked and composite codes.

Product Specification

Type	Barcode scanner - handheld
Colour	Black
Interface Type	USB
Scan Element Type	2D imager
Sensor Resolution	1280 x 800
Light Source Wave Length	650 nm
Skew (Degrees)	65
Pitch (Degrees)	65
Print Contrast Signal (PCS)	15%
Decode Capability	MaxiCode, Aztec code, MicroPDF417, Postnet, PDF417, Data Matrix, PLANET, Australian Post, British Post, China Post, Japanese Post, Kix (Netherlands) Post, MacroPDF417, RM4SCC, Royal Mail, Micro QR code, GS1 DataBar Stacked Omnidirectional, GS1 DataBar Expanded Stacked, GS1 DataBar Composites, GS1 DataBar Stacked, China Han Xin Code, UPC A Composite, UPC E Composite
TTL Decoding	Decoded
Connectivity Technology	Wired
OK Notification	Beeper, LED indicator
Features	Datalogic Three Green Lights (3GL), Green Spot technology, Digimarc Barcode Technology, Direct Part Mark (DPM)
Interfaces	1 x USB
Included Accessories	Permanent Base
Compliant Standards	RoHS, IP52
Voltage	DC 5 V
Width	6.8 cm
Depth	10.9 cm
Height	16.6 cm
Weight	161 g
Service & Support	Limited warranty - 5 years
Min Operating Temperature	0 °C
Max Operating Temperature	50 °C
Humidity Range Operating	0 - 95% (non-condensing)
Drop Specification	1.8 m to concrete
