Dell PowerEdge R230 / Server / rack-mountable / 1U / Xeon E3-1230V5 / 3.4 GHz / RAM 8 GB 3.5" / HDD 2 x 1 TB / DVD-Writer / Matrox G200 / GigE / no OS | R230-5751
Dell PowerEdge R230 / Server / rack-mountable / 1U / Xeon E3-1230V5 / 3.4 GHz / RAM 8 GB 3.5" / HDD 2 x 1 TB / DVD-Writer / Matrox G200 / GigE / no OS | R230-5751
Description Powerful, efficient, versatile. Consolidate data and drive applications faster with the powerful, efficient and versatile PowerEdge R230 1-socket, 1U entry rack server. Special Features
Product features
|
Product Specification
Type | Server |
Product Form Factor | Rack-mountable - 1U |
Server Scalability | 1-way |
Internal Bays Qty | 4 |
Colour | Black |
CPU | Intel Xeon E3-1230V5 / 3.4 GHz |
Max Turbo Speed | 3.8 GHz |
Number of Cores | Quad-Core |
CPU Qty | 1 |
Max CPU Qty | 1 |
Processor Main Features | Intel Turbo Boost Technology 2 |
Chipset Type | Intel C236 |
Installed Size | 8 MB |
Cache Per Processor | 8 MB |
Installed Size | 8 GB / 64 GB (max) |
Technology | DDR4 SDRAM - ECC |
Effective Memory Speed | 2133 MHz |
Form Factor | DIMM 288-pin |
Features | Unbuffered |
Configuration Features | 1 x 8 GB |
Type | HDD |
Capacity | 2 x 1 TB |
Interface Type | SATA |
Spindle Speed | 7200 rpm |
Type | 1 x RAID |
Controller Interface Type | SATA 6Gb/s / SAS 12Gb/s |
Storage Controller Name | Dell PERC H330 |
RAID Level | RAID 0, RAID 1, RAID 5, RAID 10, RAID 50 |
Type | DVD-Writer |
Monitor Type | None. |
Graphics Processor | Matrox G200 |
Video Memory | 16 MB |
Video Interfaces | VGA |
Ethernet Ports | 2 x Gigabit Ethernet |
Ethernet Controller | Broadcom BCM5720 |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
Remote Management Controller | Integrated Dell Remote Access Controller 8 Express (iDRAC8) |
Bays | 4 (total) / 2 (free) x 3.5" ¦ 1 (total) / 0 (free) x 5.25" Slim Line |
Slots | 1 (total) / 0 (free) x CPU ¦ 1 PCIe 3.0 x8 ¦ 4 (total) / 3 (free) x DIMM 288-pin |
Interfaces | 2 x VGA ( 1 front, 1 rear ) ¦ 2 x LAN (Gigabit Ethernet) ¦ 1 x serial ¦ 2 x USB 2.0 ( 2 in front ) ¦ 2 x USB 3.0 |
Included Accessories | Bezel |
Pricing Type | BTO |
Device Type | Power supply |
Installed Qty | 1 |
Nominal Voltage | AC 120/230 V ( 50/60 Hz ) |
Power Provided | 250 Watt |
80 PLUS Certification | 80 PLUS Bronze |
OS Provided | No operating system |
Service & Support | Limited warranty - 3 years - response time: next business day |
Width | 43.415 cm |
Height | 4.28 cm |
Min Operating Temperature | 10 °C |
Max Operating Temperature | 35 °C |
Humidity Range Operating | 10 - 80% |
