Dell Networking S5248F-ON - Switch - L3 - Managed - 48 x 25 Gigabit SFP28 + 4 x 100 Gigabit QSFP28 + 2 x 200 Gigabit QSFP28-DD - front to back airflow - rack-mountable - Dell Smart Value | 210-APEX
210-APEX
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
Product Specification
| Device Type | Switch - 48 ports - L3 - Managed |
| Enclosure Type | Front to back airflow rack-mountable 1U |
| Subtype | 25 Gigabit Ethernet |
| Ports | 48 x 25 Gigabit SFP28 + 4 x 100 Gigabit QSFP28 + 2 x 200 Gigabit QSFP28-DD |
| Performance | Switching capacity: 2 Tbps |
| Capacity | MAC addresses: 160000 ¦ ARP entries: 128000 ¦ IPv4 routes: 128000 ¦ IPv6 routes: 64000 ¦ Multicast hosts: 32000 ¦ Link aggregation groups: 16 ¦ Layer 2 VLANs: 4000 ¦ MSTP instances: 64 |
| Routing Protocol | OSPF, BGP-4, OSPFv2, OSPFv3, policy-based routing (PBR) |
| Remote Management Protocol | SNMP 1, SNMP 2, TFTP, SSH-2, CLI, SCP |
| Encryption Algorithm | MD5 |
| Authentication Method | RADIUS, TACACS |
| Features | Flow control, ARP support, port mirroring, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Virtual Route Redundancy Protocol (VRRP) support, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Quality of Service (QoS), LACP support, LLDP support, Network Access Control (NAC), Priority-Based Flow Control (PFC), Internet Control Message Protocol (ICMP), DNS client, VLAN Tagging |
| Compliant Standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1t, IEEE 802.1ab (LLDP), IEEE 802.1Qbb, IEEE 802.1Qaz |
| RAM | 16 GB |
| Expansion / Connectivity | |
| Interfaces | 48 x 25Gbit LAN SFP28 ¦ 4 x 100Gbit LAN QSFP28 ¦ 2 x 200Gbit LAN QSFP28-DD ¦ 1 x serial (RS-232) RJ-45 |
| Power | |
| Power Device | Internal power supply - hot-plug |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Power Redundancy | Yes |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 400 Watt |
| Features | Front-to-rear airflow |
| Miscellaneous | |
| Compliant Standards | EN 61000-3-2, EN 61000-3-3, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, EN 61000-4-5, EN 60825-1, EN 60825-2, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, ICES-003 issue 4 Class A, EN 300 386 V1.4.1, AS/NZS CISPR22:2006 Class A, FDA 21CFR1040.10, EN 55022:2006+A1:2007 Class A, FDA 21CFR1040.11, VCCI V-3/2009 Class A, EU RoHS, UL/CSA60950-1 (2nd Edition), FCC CFR47 Part 15 B 2011 Class A, EN 55024:1998+A1:2001+A2:2003 |
| Manufacturer Selling Program | Dell Smart Value |
| Software / System Requirements | |
| OS Required | Dell Networking OS 10 |
| Dimensions & Weight | |
| Width | 43.4 cm |
| Depth | 46 cm |
| Height | 4.4 cm |
| Weight | 9.7 kg |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year - carry-in |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 45 °C |
| Humidity Range Operating | 5 - 90% (non-condensing) |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 5 - 90% (non-condensing) |
