Product Features
- Combo converter
The big advantage of this Delock M.2 converter is that both SATA and PCIe (NVMe) M.2 SSDs can be inserted into the converter. The memory is automatically recognized by the chipset and can then be used. - Ideal test equipment
Due to the USB-A connector and the direct installation of the SSD on the board, without enclosure, the Delock converter is most suitable as test equipment.
Special Fetures
- Supports M.2 modules in format 2280, 2260, 2242 and 2230 with key M or key B+M
- Based on SATA or PCIe (NVMe)
- Supports NVM Express (NVMe)
- Data transfer rate up to 10 Gbps
- LED indicator for power and access
- Plug-and-Play
Product Specification
| Device Type | Interface adapter - external |
| Hard Drive Form Factor Compatibility | M.2 |
| Hard Drive Maximum Height | 1.5 mm |
| Host Bus | USB 3.2 (Gen 2) |
| Storage Controller | |
| Interface | M.2 Card (PCIe NVMe & SATA) |
| Data Transfer Rate | 10 Gbit/s |
| Supported Devices | Solid state drive |
| Max Storage Devices Qty | 1 |
| Processor | Realtek Semiconductor RTL9210B |
| Expansion / Connectivity | |
| Bays | 1 M.2 2230/2242/2260/2280 |
| Interfaces | 1 x M.2 Card - 67 pin key B+M slot |
| Connections | 1 x USB 3.2 (Gen 2) - 9 pin USB Type A |
| Miscellaneous | |
| Included Accessories | Screwdriver |
| Features | LED indicator, supports NVM Express, bootable |
| Compliant Standards | Plug and Play |
| Package Type | Retail |
| Software / System Requirements | |
| OS Required | Google Chrome OS, Windows 8.1 (32/64 bits), Windows 10 (32/64 bits), Windows 11, Android 11 or later, Linux Kernel 5.13 or later, Apple MacOS 12.3.1 or later |
| Dimensions & Weight | |
| Width | 2.2 cm |
| Depth | 11 cm |
| Height | 0.6 cm |
Features - DeLOCK - 64197
Interface
- USB3.2
More Details
Product Code
04:464435
EAN Code
4043619641970
Manufacturer
DeLOCK
