Digitus Unique DN-19 42U-8/8-1 - Rack - cabinet - light grey, RAL 7035 - 42U - 19" | DN-19 42U-8/8-1
Please sign in so that we can notify you about a reply
Product Features
· Safety class rating IP20· Complete metal frame front door with safety glass
· Lock system with pivot lever on front door (ready for profile half cylinder; adapter included)
· 120° door opening angle on front- and rear doors
· Double wing opening rear door
· 1-point-locking-mechanism on all doors
· Side panels are lockable and removable
· incl. 4 pieces of leveling feet already pre-configured under the rack
· 483 mm (19) profile rails mounted on the front- and rear side inside of the rack, galvanized
· 483 mm (19) profile rails are adjustable in depth and with height unit marking
· Built-in depth support bars for more stability
· Vertical cable management ducts in the front
· Sliding cable entry with rubber sealing on the base
· Cable entry with brush strip at the top and bottom of the cabinet rear side
· Top and base with brushed cable entries left and right
· Special roof construction for fan unit with added lid which can be unmounted
· Several earthing points for rack components
· Incl. installation set (screws, cage nuts, washers)
· Rack is completely mounted
· Equipment mounting depth min.-max.: 563-743 mm
Special Fetures
· Special roof construction for fan unit with added lid which can be unmounted· Lock system with pivot lever on front door (ready for profile half cylinder; adapter included)
· Sliding cable entry with rubber sealing on the base
Product Specification
| Product Type | Rack |
| Rack Type | Cabinet |
| Product Material | Powder-coated steel |
| Rack Size | 19" |
| Height (Rack Units) | 42U |
| Width | 80 cm |
| Depth | 80 cm |
| Height | 205.3 cm |
| Colour | Light grey, RAL 7035 |
| Miscellaneous | |
| Weight Limit | 600 kg |
| Features | Lockable rear door, adjustable depth, lockable side panel, removable side panel, glass door, vertical cable management |
| Compliant Standards | IEC 297-1/2, IEC 917-2-1, IP40 |
Features - Digitus - DN-19 42U-8/8-1
More Details
Product Code
03:149196
EAN Code
4016032334217
Manufacturer
Digitus
