DuraScan D740 / With charging dock / barcode scanner / portable / linear imager / decoded / Bluetooth 2.1 EDR | CX3472-1940
Description
The DuraScan D740, v20 is the latest version of our universal Bluetooth barcode scanner built for mobility. Redesigned for improved durability, it is IP54 compliant, ideal for warehousing and manufacturing application customers. In addition, Socket Mobile has added a field-replaceable battery compartment based on customer feedback. The scanner is MFi certified and fully compatible with Android and Windows.The D740, v20 reads all 2D/1D barcodes on paper and screen. It features great ergonomics and fits perfectly in your hand. It is designed for comfort and extended use; it is light, highly durable and small enough to fit in your pocket.
DuraScan D740 / With charging dock | CX3472-1940
Special Features
- Wireless freedom with long-range Bluetooth connection
- Exceptional ergonomics
- Long lasting battery
- Intuitive LED indicators let users know battery, Bluetooth connection and scanning status at a glance
- Application mode improves business productivity with faster, efficient and reliable data transfer
- User feedback with audible tones and hand pulsation
- Dust protection and protection from splashing water
- Rugged design
- Made with antimicrobial material for easy cleaning and protection against potential harmful microbes
- Wearable
Product Specification
| Type | Barcode scanner - portable |
| Colour | Utility grey |
| Interface Type | Bluetooth 2.1 EDR |
| Scan Element Type | Linear imager |
| Light Source Wave Length | 650 nm |
| Max Working Distance | 2.54 m |
| Print Contrast Signal (PCS) | 25% |
| Decode Capability | Matrix 2 of 5, Industrial 2 of 5, Code 39, UCC/EAN-128, ISBT 128, GS1 DataBar, QR code, MaxiCode, Aztec code, Bookland, Code 32, Code 39 Full ASCII, UPC-A, UPC-E, MicroPDF417, Codabar, Code 128, Code 11, Interleaved 2 of 5, Postnet, PDF417, Data Matrix, PLANET, TLC39, Australian Post, British Post, Canadian Post, China Post, Japanese Post, Kix (Netherlands) Post, IATA 2 of 5, UPC-E1, Plessey, Code 39 Trioptic, UK Post, OCR-A, Micro QR code, GS1 DataBar Omnidirectional, GS1 DataBar Stacked Omnidirectional, GS1 DataBar Expanded Stacked, GS1 DataBar Limited, Swedish Post, Info Mail, Standard 2 of 5, GS1 DataBar Stacked, Intelligent Mail Barcode, MSI, Chinese 2 of 5, RSS-14, UPU FICS, RSS Expended, Composite C, US Postnet, USPS 4-state (US4CB), Straight 2 of 5, Han Xin, Korean 3 of 5 |
| TTL Decoding | Decoded |
| Connectivity Technology | Wireless |
| OK Notification | LED indicator |
| Features | Human Interface Device Profile (HID), Serial Port Profile (SPP) |
| Wireless Connectivity | Bluetooth 2.1 EDR |
| Compliant Standards | C-Tick, EN55022, ICES-003, EN55024, CISPR 22, RSS-210, IC, FCC Part 15 C, RoHS, IEC 60950-1, WEEE, IEC 60068-2-32, IEC 60825-1, TELEC, EN 60825-1, IP54, IEC 60068-2-31 |
| Battery | 1 x Lithium Ion |
| Width | 3.71 cm |
| Depth | 13.22 cm |
| Height | 4.01 cm |
| Weight | 112.5 g |
| Service & Support | Limited warranty - 1 year |
| Min Operating Temperature | -20 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 0 - 95% (non-condensing) |
| Drop Specification | 1.5 m to concrete |
Features - Socket - CX3472-1940
More Details
Product Code
Y340527
EAN Code
0758497114365
Manufacturer
Socket
