Eaton Ellipse ECO 1600 USB DIN / UPS (rack-mountable / external) / AC 230 V / 1000 Watt / 1600 VA / USB / output connectors: 8 / 2U / 19" | EL1600USBDIN

Description

As well as providing a power supply backed up by a battery to keep equipment operating during a power failure, the Ellipse Eco also provides effective protection against damaging surges. The Eco Control function automatically disables peripherals when the master device is turned off in order to save up 25 % more energy compared to previous generation of UPS. This unit can either be placed horizontally, 19 inch rack mounted or wall mounted. The Ellipse Eco also includes the Eaton Intelligent Power Manager software. It is an ideal protection for all business computers.

Special Features

  • EcoControl function helps you save up to 25% energy compared to previous generation UPSs
  • Includes a high performance surge-protection device which complies with IEC 61643-1 standard
  • Convenient extra-flat design for easy installation in any office environment
  • Protects data connections such as Ethernet, Internet and telephone lines

Product features

  • Energy-efficient power protection for business computers
    With an efficient electrical design and the EcoControl function, which automatically disables peripherals when the master device is turned off, the Eaton Ellipse ECO helps you make energy savings of up to 25 percent compared to previous-generation UPSs. As well as providing a power supply backed up by a battery to keep equipment operating during a power failure, the Ellipse ECO also provides effective protection against damaging surges.
  • Easy integration and installation
    The Ellipse ECO's extra-flat design makes it easy to install in any office environment: installation options include vertical box format, below the desk, horizontally under a monitor and 19" rack-mounted.
  • Complete peace of mind
    Periodic battery self-test ensures early detection of a battery that needs to be replaced. Easy-to-replace battery helps to extend UPS service life. Push-button circuit breaker enables easy recovery from an overload or short circuit.

Product Specification

Device Type UPS - rack-mountable / external
Height (Rack Units) 2U
Rack Size 19"
UPS Technology Off-line
Input Voltage AC 230 V
Input Voltage Range AC 184 - 264 V
Input Voltage Range (Adjustable) AC 161 - 284 V
Frequency Provided 50/60 Hz
Frequency Required 50/60 Hz
Input Connectors 1 x power
Power Output Connectors Details 4 (UPS and surge) ¦ 4 (surge)
Output Voltage AC 220/230/240 V 50/60 Hz
Power Capacity 1000 Watt / 1600 VA
Dataline Surge Protection Network/phone line - RJ-45/RJ-11
Surge Suppression Yes
Circuit Protection Circuit breaker
Technology Lead Acid
Run Time (Up To) 11 min at half load ¦ 6 min at 70% load
Remote Management Interface USB
Interfaces 1 x management (USB) - 4 pin USB Type B
Cables Included USB cable - external
Rack Mounting Kit Optional
Features Wall mountable, audible alarm, LED indicators, deep discharge protection, cold-start function, Eco-efficiency
Compliant Standards CB, IEC 62040-1-1, IEC 62040-2, IEC 60950-1, IEC 61643-1
Software Included Intelligent Power Manager
OS Required Linux, Apple MacOS X, Microsoft Windows Vista / XP / 7
Service & Support Limited warranty - 2 years
Width 8.1 cm
Depth 31.2 cm
Height 30.5 cm
Weight 7.8 kg
