Edimax Pro CAP 1300 - Radio access point - Wi-Fi 5 - 2.4 GHz, 5 GHz - wall / ceiling mountable | CAP1300

Edimax Pro CAP 1300 - Radio access point - Wi-Fi 5 - 2. | CAP1300

Description
Features
Reviews

Product Features

Superior high-speed Wi-Fi
Supports incredible wireless speeds for high bandwidth data or video transmission.
Efficiently serves multiple devices
Connects more devices simultaneously with two MU-MIMO spatial streams and enhances Wi-Fi efficiency.
Optimal Wi-Fi performance
Featuring beamforming, band steering improved Wi-Fi range, reliability and performance.

Special Fetures

Superior high-speed Wi-Fi
Efficiently serves multiple devices
Optimal Wi-Fi performance

Product Specification

Device Type	Radio access point
Width	17.6 cm
Depth	17.6 cm
Height	3.2 cm
Weight	342 g
Networking
Form Factor	Wall / ceiling mountable
Connectivity Technology	Wireless
Data Transfer Rate	1300 Mbps
Data Link Protocol	IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
Network / Transport Protocol	PPTP, L2TP, IPSec
Remote Management Protocol	SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, CLI
Frequency Band	2.4 GHz, 5 GHz
Status Indicators	Power, diagnostic
Features	Power over Ethernet (PoE), VPN support, VLAN support, manageable, MAC address filtering, IPv6 support, Wireless Distribution System (WDS) support, Rapid Spanning Tree Protocol (RSTP) support, Quality of Service (QoS), RADIUS support, roaming function, Wi-Fi Protected Setup (WPS), Multiple SSID support, hidden SSID, reset button, Management Information Base (MIB), ceiling mountable, DiffServ Code Point (DSCP) support
Encryption Algorithm	WPA, WPA2, WEP
Authentication Method	Extensible Authentication Protocol (EAP), EAP-FAST
Compliant Standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.1x, IEEE 802.11e, IEEE 802.11n, IEEE 802.3at, IEEE 802.3az, IEEE 802.11ac
Aerial
Antenna	Internal
Antenna Qty	4
Expansion / Connectivity
Interfaces	1 x 1000Base-T (PoE) - RJ-45 ¦ 1 x 1000Base-T - RJ-45
Miscellaneous
Included Accessories	Ceiling mounting kit, T-Rail mounting kit
Cables Included	Network cable
Compliant Standards	FCC, RoHS, UL 94
Power
Power Over Ethernet (PoE) Supported	PoE
Power Device	External power adapter
Power Consumption Operational	11 Watt
Environmental Parameters
Min Operating Temperature	0 °C
Max Operating Temperature	40 °C
Humidity Range Operating	0 - 90%
