Elo 1717L Rev B LED monitor 17" 1280 x 1024 5 ms VGA black TOUCHDISPLAY

Elo Touch Solutions 0V00056

Hover over an image to enlarge

795.94
(Including VAT)
Out of stock
E017030
Product Code:0V00056
EAN Code:7411493347542
Manufacturer:Elo Touch Solutions
Screen Size:17"

Free Store
Pickup

Delivery within 2-4
business days

2 Years Warranty

Elo Touch Solutions E017030 Elo 1717L Rev B LED monitor 17" 1280 x 1024 5 ms VGA black TOUCHDISPLAY

Elo 1717L Rev B LED monitor 17" 1280 x 1024 5 ms VGA black TOUCHDISPLAY

The 1717L touchmonitor is built to withstand the rigors of continuous public use with a rugged "built for touch" design. Its stylish, thin and modern look is coupled with a retail-focused feature set and is an attractive solution for commercial touchmonitor needs. It is well suited for high use public venues where point-of-sale, point-of-information, point-of-service, shelf-level and countertop interactive digital signage and loyalty systems systems are found.

The 1717L is offered with AccuTouch five-wire resistive technology, IntelliTouch surface acoustic wave, or iTouch pure glass surface acoustic wave technology. AccuTouch is widely used in retail and hospitality environments based on its proven ability to survive splashing liquids, food and grease. IntelliTouch and iTouch pure glass surface acoustic wave technology delivers the ultimate in optical quality for dry retail and hospitality applications.

The optional 3-track magnetic stripe reader MSR, programmable to either HID or Keyboard Emulation, is easily installed by the user, providing an elegant, integrated solution and eliminating the need for external brackets or attachments.

The 1717L touchmonitor is environmentally friendly, lightweight and uses less power with state-of-the-art LED backlights in the display panel.

- Sleek and thin design with “Built for Touch” Reliability.
- Flexible and space-saving.
- 40% Energy savings using LED technology.
- Zero-bezel touchscreen versions for a smooth, easy-to-clean surface.
- Antiglare or Clear glass.
- Removable base and mounting options including VESA, wall and pole-mounting for installation flexibility and capped through-mount holes on base for table-top security.
- 17” diagonal active matrix TFT LED-backlit LCD.
- Active Display Area: 13.3 x 10.6 inches/338 x 270 mm.
- 5:4 aspect ratio.
- 1280 x 1024 native resolution. Other resolutions supported.
- USB and RS232 serial connections.
- Touch technology: AccuTouch single- touch, IntelliTouch single-touch and iTouch single-touch.
- Typical power consumption: 20W, internal and external power options.

Feature list

Display diagonal: 17 "
Response time: 5 ms
Display brightness: 225 cd/m²
Contrast ratio typical: 800:1
Display type: LCD
Display resolution: 1280 x 1024 pixels
Number of colours: 16.7 M
Horizontal scan range: 31.5 - 80 kHz
Vertical scan range: 56 - 75 Hz
Viewing angle, horizontal: 170 °
Viewing angle, vertical: 160 °
Aspect ratio: 5:4
Display viewable area HxV: 338 x 270 mm
LED backlight: Y
Supported graphics resolutions: 720 x 400, 1024 x 768 XGA, 1280 x 1024 SXGA, 640 x 480 VGA, 800 x 600 SVGA
Touch screen type: Tabletop
Mean time between failures MTBF: 50000 h
Number of OSD languages: 8
On Screen Display OSD languages: CHI SIMPL, CHI TR, DEU, ENG, ESP, FRE, ITA, JPN
USB 2.0 ports quantity: 1
VGA D-Sub ports quantity: 1
RS-232 ports: 1
Colour of product: Black
Glass thickness: 43 mm
VESA mounting interfaces compatibility: 75 x 75 mm
Power supply type: AC/DC
Power consumption typical: 20 W
Input voltage: 100 - 240 V
Input frequency: 50/60 Hz
Voltage tolerance: 5 %
Operating temperature T-T: 0 - 40 °C
Storage temperature T-T: 20 - 60 °C
Operating relative humidity H-H: 20 - 80 %
Storage relative humidity H-H: 10 - 90 %
Dimensions W x D x H with stand: 392 x 215 x 361 mm
Weight with stand: 5400 g
Packaging width: 511 mm
Packaging depth: 233 mm
Packaging height: 510 mm
Package weight: 8300 g

Elo 1717L Rev B LED monitor 17" 1280 x 1024 5 ms VGA black TOUCHDISPLAY

Screen Size :
17"

More Details

Product Code:
0V00056
EAN Code:
7411493347542
Manufacturer:
Elo Touch Solutions
