Elo Computer Module ECMG4-i5 / Digital signage player / 8 GB RAM / Intel Core i5 / SSD / 256 GB / Windows 10 IoT Enterprise LTSC 64-bit / black | E228087

E228087
1,239.27
(1,474.73 inc. VAT)
Out of stock
Delivery
Payment options
Product Code0V01054 EAN Code0843173102832 ManufacturerElo

Product Features

  • Smaller form factor
    With dimensions of 11.07x8.2x1.7 the new ECMG4 form factor is 47% smaller than the previous model, delivering a lower cost, lower energy consumption computer module that's easier to install and maintain.
  • Easy installation
    The Elo IDS Computer Modules slide into the back of the touchscreen display to deliver the industry's thinnest commercial grade all-in-one large format touchcomputers. Field installation is easy with no external cables required. AC power, video and USB signals pass between the computer module and the Elo IDS touch display via an internal docking connector.
  • Collaboration ready
    Pair the flexibility of Elo's 6553L Interactive Board with a seamless, bring-your-own-device, content sharing software to offer employees and corporations countless business benefits. Elo's ECMG4 comes conferencing ready with the DisplayNote Montage Software included. From increased efficiency to controlled costs - start connecting teams and information in real time to empower better, faster, more reliable decision making and improving the way collaboration works.

Special Features

  • Smaller form factor
  • Easy installation
  • Collaboration ready

Product Specification

Device Type Digital signage player
Width 28.11 cm
Depth 20.82 cm
Height 4.3 cm
Weight 2.1 kg
Colour Black
OS Provided Windows 10 IoT Enterprise LTSC 64-bit Edition
Interfaces USB 2.0, Gigabit Ethernet, USB 3.0
Key Features Digital audio player, digital photo viewer, digital video player, Wi-Fi
Processor Processor
Manufacturer Intel
Type Core i5
Installed Qty 1
Processor Number I5-7500T
Number of Cores Quad-Core
Clock Speed 3.3 GHz
RAM RAM
Technology DDR4 SDRAM
Installed Size 8 GB
Max Supported Size 64 GB
Slots Qty 2
Digital Storage Digital Storage
Storage Drive Type SSD
Capacity 256 GB
Video Output Video Output
Graphics Processor Intel HD Graphics 630
Memory / Storage Memory / Storage
Storage Drive Capacity 256 GB
Storage Drive Form Factor M.2
Connectivity Connectivity
Connections HDMI output ¦ 2 x USB 3.0 ¦ 2 x USB 2.0 ¦ LAN (Gigabit Ethernet) ¦ Audio line-out - mini-jack ¦ Microphone - mini-jack ¦ 2 x aerial
Miscellaneous Miscellaneous
Included Accessories 2 x aerials
Compliant Standards UL, VCCI, cUL, CB, FCC, AS/NZS
Dimensions & Weight (Shipping) Dimensions & Weight (Shipping)
Shipping Width 73 cm
Shipping Depth 52 cm
Shipping Height 32 cm
Shipping Weight 3.3 kg
Manufacturer Warranty Manufacturer Warranty
Service & Support Limited warranty - 3 years
Environmental Parameters Environmental Parameters
Min Operating Temperature 0 °C
Max Operating Temperature 40 °C
Humidity Range Operating 20 - 80% (non-condensing)

Features - Elo - E228087

More Details
Product Code
0V01054
EAN Code
0843173102832
Manufacturer
Elo
