EVGA 600 BR / Power supply (internal) / ATX12V / EPS12V / 80 PLUS Bronze / AC 100-240 V / 600 Watt / active PFC / Europe | 100-BR-0600-K2
Product Specification
| Device Type | Power supply - active Power Factor Correction (PFC) - internal |
| Specification Compliance | ATX12V / EPS12V |
| PSU Form Factor | ATX |
| Localisation | Europe |
| Input Voltage | AC 100-240 V |
| Frequency Required | 50 - 60 Hz |
| Power Output Connectors Details | 1 x power 24 pin ATX ¦ 1 x power 8 pin EPS12V with detachable 4 pin ATX12V section ¦ 2 x 8 pin PCI Express power with detachable 2 pin section ¦ 3 x 4 PIN internal power ¦ 6 x 15 pin Serial ATA power ¦ 1 x 4 PIN mini-power connector |
| Output Voltage | +3.3, +5, ±12 V |
| Power Capacity | 600 Watt |
| Output Current | +5V - 20 A ¦ +3.3V - 24 A ¦ +12V - 50 A ¦ -12V - 0.3 A ¦ +5VSB - 3 A |
| Efficiency | 85% |
| 80 PLUS Certification | 80 PLUS Bronze |
| MTBF | 100,000 hour(s) |
| Cooling System | 120 mm fan |
| Features | Over current protection, over voltage protection, overpower protection, undervoltage protection, short-circuit protection, single 12V rail, thermal protection, DC-DC technology, sleeve bearing cooling fan, non-modular |
| Compliant Standards | TUV, CB, FCC, RoHS, WEEE, cTUVus, RCM, ErP Lot 6 2013 Ready |
| Service & Support | Limited warranty - 3 years |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 30 °C |
| Width | 15 cm |
| Depth | 14 cm |
| Height | 8.5 cm |
| Weight | 1.81 kg |
Features - EVGA - 100-BR-0600-K2
More Details
Product Code
03:158930
EAN Code
4250812423658
Manufacturer
EVGA
