EVGA SuperNOVA 650 P2 / Power supply (internal) / ATX / 80 PLUS Platinum / AC 100-240 V / 650 Watt / Europe | 220-P2-0650-X2
|
Description Advanced performance of the EVGA SuperNOVA P2 power supply provides clean and continuous power to every component. The ECO Control Fan system offers fan modes to provide absolutely zero fan noise during low load to medium load operations. Special Features
|
Product Specification
| Device Type | Power supply - internal |
| Specification Compliance | ATX |
| Localisation | Europe |
| Input Voltage | AC 100-240 V |
| Frequency Required | 50 - 60 Hz |
| Power Output Connectors Details | 1 x power 24 pin ATX ¦ 2 x power 8 pin EPS12V with detachable 4 pin ATX12V section ¦ 2 x 8 pin PCI Express power with detachable 2 pin section ¦ 2 x 6 pin PCI Express power ¦ 9 x 15 pin Serial ATA power ¦ 6 x 4 PIN internal power ¦ 1 x 4 PIN mini-power connector |
| Output Voltage | +3.3, +5, ±12 V |
| Power Capacity | 650 Watt |
| Output Current | +5V - 20 A ¦ +3.3V - 20 A ¦ +12V - 54.1 A ¦ -12V - 0.5 A ¦ +5VSB - 2.5 A |
| Efficiency | 92% (115VAC) / 94% (220-240VAC) |
| 80 PLUS Certification | 80 PLUS Platinum |
| Included Accessories | Cable bag |
| MTBF | 100,000 hour(s) |
| Cooling System | 140 mm fan |
| Features | Over current protection, over voltage protection, overpower protection, SLI ready, CrossFire ready, undervoltage protection, cable management, short-circuit protection, single 12V rail |
| Compliant Standards | TUV, BSMI, CB, FCC, RoHS, WEEE, cTUVus, Energy-Related Products (ErP) Lot 6, RCM |
| Service & Support | Limited warranty - parts and labour - 10 years with product registration |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Width | 15 cm |
| Depth | 16.5 cm |
| Height | 8.5 cm |
| Weight | 2.72 kg |
Features - EVGA - 220-P2-0650-X2
More Details
Product Code
04:332071
EAN Code
4250812408532
Manufacturer
EVGA
