Fractal Design Meshify 2 / Tower / extended ATX / windowed side panel (tempered glass) / no power supply (ATX) / black / USB/Audio | FD-C-MES2A-03
Please sign in so that we can notify you about a reply
Product Features
- Detachable front filter
New front nylon filter that can be removed for increased airflow. New front panel design with hinged removable mesh and tether-free bezel for easier access to front fan mounts. Three Dynamic X2 GP-14 fans come preinstalled with room to expand up to a total of nine fans. - Superlative storage
Convert to storage layout and install up to 11 HDDs alongside four dedicated SSDs mounts (6x SSD/HDD trays, 2x SSD brackets and 1x multibracket included). Transformable interior design utilizing a movable wall for enhancing custom builds. The included multibracket lets you convert any unused fan position to an HDD, SSD or pump mount. Tool-less, top-latching side panels allow quick access while preventing accidental drops. - Extremely flexible
Fits your custom water loop with large reservoirs and radiators up to 420 mm in the default Open Layout. Support for radiators up to 360 mm (front), 420 mm (top) and 280 mm (base). Easily holds large motherboards up to and including 285 mm E-ATX. - Open and interchangeable
Remove the entire top to build and route with zero hindrance. - Type-C interface
USB 3.1 Gen 2 Type-C front I/O offers fast-charging and speeds up to 10 Gbps. - Nexus+ 2 fan hub
Ultra-slim Nexus+ 2 fan hub connects up to three PWM fans and six 3-pin fans. - Versatile multibracket
Versatile multibracket that converts any unused fan position to an HDD, SSD or pump mount. - Cable management
Detachable PSU cable shield and integrated cable guides with Velcro straps further simplify cable management behind the board.
Special Features
- Iconic angular mesh design provides filtered airflow with a bold, stealth-inspired aesthetic
- Spacious adaptable interior for motherboards up to (and including) 285 mm E-ATX
- Support for radiators up to 360 mm (front), 420 mm (top) and 280 mm (base)
- Detachable front filter
- Superlative storage
- Extremely flexible
- Open and interchangeable
- Type-C interface
- Nexus+ 2 fan hub
- Versatile multibracket
- Cable management
Product Specification
| Form Factor | Tower |
| Windowed Side Panel | Yes |
| Windowed Side Panel Material | Tempered glass |
| Max Mainboard Size | Extended ATX |
| Supported Motherboards | ATX, microATX, Mini-ITX, Extended ATX |
| Internal Bays Qty | 8 |
| Product Material | Steel |
| Colour | Black |
| Cooling System | Front: 140 mm fan x 2 / 3 x 120/140 mm fan or 280/360mm radiator supported ¦ Rear: 140 mm fan x 1 / 1 x 120/140 mm fan or 120mm radiator supported ¦ Top: 120/140 mm fan mount x 3 / 360/420mm radiator supported ¦ Bottom: 120/140 mm fan mount x 2 / 240/280mm radiator supported |
| CPU Cooler Max Height | 185 mm |
| Video Card Max Length | 491 mm |
| Power Supply Max Length | 250 mm |
| System Cabinet Features | Top panel dust filter, front dust filter, cable management system, bottom dust filter, light tint tempered glass left side panel |
| Expansion / Connectivity | Expansion / Connectivity |
| Expansion Bays | 6 (total) / 6 (free) x internal - 2.5" / 3.5" shared ¦ 2 (total) / 2 (free) x internal - 2.5" |
| Expansion Slots | 9 |
| Interfaces | 2 x USB 3.0 ¦ USB 3.1 Gen 2 - USB-C ¦ 1 x microphone - mini-jack ¦ 1 x headphones - mini-jack |
| Power | Power |
| Power Device | No power supply |
| Specification Compliance | ATX |
| Dimensions & Weight | Dimensions & Weight |
| Width | 24 cm |
| Depth | 54.2 cm |
| Height | 47.4 cm |
| Weight | 10.5 kg |
| Dimensions & Weight (Shipping) | Dimensions & Weight (Shipping) |
| Shipping Width | 32.4 cm |
| Shipping Depth | 54.2 cm |
| Shipping Height | 63.4 cm |
| Shipping Weight | 13.2 kg |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 2 years |
Features - Fractal Design - FD-C-MES2A-03
More Details
Product Code
07:128761
EAN Code
7340172702443
Manufacturer
Fractal Design
