Gigabyte GeForce RTX 3060 Ti GAMING OC 8G (rev. 2.0) / Graphics card / GF RTX 3060 Ti / 8 GB GDDR6 / PCIe 4.0 x16 / 2 x HDMI, 2 x DisplayPort | GV-N306TGAMING OC-8GD 2.0

GV-N306TGAMING OC-8GD 2.0
539.58
586.50
(642.10 inc. VAT) You save: 46.92
Out of stock
Find similar
Delivery
Payment options
Product Code03:182824 EAN Code4719331309794 ManufacturerGigaByte GPUGeForce RTX 3060

Product Features

  • WINDFORCE 3X cooling system
    The WINDFORCE 3X cooling system features 3x 80mm unique blade fans, alternate spinning, 3 composite copper heat pipes direct touch GPU, 3D active fan and Screen cooling, which together provide high efficiency heat dissipation.
  • Alternate Spinning
    Alternate Spinning can reduce the turbulence of adjacent fans and increase air pressure.
  • Smooth airflow
    GIGABYTE turns the adjacent fans in the opposite direction, so that the airflow direction between the two fans is the same, reducing the turbulence and enhancing the airflow pressure.
  • 3D Active Fan
    The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.
  • UNIQUE BLADE FAN
    The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface.
  • Graphene nano lubricant
    Graphene nano lubricant can extend the life of fan by 2.1 times, close to the life of double ball bearing, and is quieter.
  • Screen cooling
    Extended heatsink design allows air flow to pass through, providing better heat dissipation.
  • Heat pipes direct touch
    The shape of the pure copper heat pipe maximizes the direct contact area with the GPU. The heat pipe also covers the VRAM through a large metal plate contact to ensure proper cooling.
  • RGB Fusion 2.0
    With 16.7M customizable color options and numerous lighting effects, you can choose lighting effects or synchronize with other AORUS devices.
  • Protection metal back plate
    The metal back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.
  • Power indicator
    When experiencing any power supply abnormality, the indicator will alert gamers by flashing light.
  • Extreme durability and overclocking
    The graphics card uses the better power phase design to allow the MOSFET to operate at lower temperature, and over-temperature protection design and load balancing for each MOSFET, plus the Ultra Durable certified chokes and capacitors, to provide excellent performance and longer system life.
  • Friendly PCB design
    Fully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.
  • AORUS engine
    The cutting edge intuitive interface allows you to adjust the clock speed, voltage, fan performance and power target in real-time according to your game's requirements.

Special Features

  • NVIDIA Ampere Streaming Multiprocessors
  • 2nd Generation RT Cores
  • 3rd Generation Tensor Cores
  • Powered by GeForce RTX 3060 Ti
  • Integrated with 8GB GDDR6 256-bit memory interface
  • WINDFORCE 3X Cooling System with alternate spinning fans
  • RGB Fusion 2.0
  • Protection metal back plate
  • LHR (Lite Hash Rate) version

Product Specification

Device Type Graphics card
Bus Type PCI Express 4.0 x16
Graphics Engine NVIDIA GeForce RTX 3060 Ti
Core Clock 1740 MHz
CUDA Cores 4864
Max Resolution 7680 x 4320
Max Monitors Supported 4
Interfaces 2 x DisplayPort ¦ 2 x HDMI
API Supported OpenGL 4.6, DirectX 12 Ultimate
Features GIGABYTE WindForce 3x, Heat Pipe Direct Touch technology, RGB Fusion 2.0, Gigabyte Alternate Spinning, NVIDIA Ampere GPU technology, 3D Active Fan, LHR (Lite Hash Rate), 2nd gen Ray Tracing Cores, 3rd gen Tensor Cores
Memory Memory
Size 8 GB
Technology GDDR6 SDRAM
Effective Clock Speed 14000 MHz
Bus Width 256-bit
Bandwidth 448 GBps
System Requirements System Requirements
Required Power Supply 600 W
Additional Requirements 8 pin PCI Express power connector
Miscellaneous Miscellaneous
Software Included AORUS Engine
Compliant Standards DisplayPort 1.4a
Width 4.1 cm
Depth 28.2 cm
Height 11.7 cm

Features - GigaByte - GV-N306TGAMING OC-8GD 2.0

GPU
GeForce RTX 3060
More Details
Product Code
03:182824
EAN Code
4719331309794
Manufacturer
GigaByte
