Gigabyte Z690M AORUS ELITE AX DDR4 / 1.0 / motherboard / micro ATX / LGA1700 Socket / Z690 Chipset / USB-C Gen2, USB 3.2 Gen 1, USB 3.2 Gen 2, USB-C Gen 2x2 / 2.5 Gigabit LAN, Wi-Fi, Bluetooth / onboard graphics (CPU required) | Z690M AORUS ELITE AX DDR4
Please sign in so that we can notify you about a reply
Product Features
- Unparalleled performance
GIGABYTE Z690 Series motherboards come with an upgraded power solution, latest storage standards and outstanding connectivity to enable optimize performance for gaming. - Advanced connectivity
GIGABYTE Z690 Series motherboards let you experience ultimate connection flexibility and blazing data-transfer speed with next generation network, storage, and Wi-Fi connectivity. - Ultra Durable
GIGABYTE Ultra Durable features its product durability and high-quality manufacturing process. GIGABYTE motherboards use the best components and reinforce every slots to make each of them solid and durable.
Special Features
- Dual-channel non-ECC unbuffered DDR4, four DIMMs
- Direct 12+1+2 digital VRM design with 60A power stage and tantalum polymer capacitor
- Shielded memory routing to avoid interference
- Fully covered thermal design with high coverage MOSFET heatsinks
- Wi-Fi 6 802.11ax 2T2R and BT5 with AORUS antenna
- Fast Intel 2.5GbE LAN with bandwidth management
- Triple ultra-fast NVMe PCIe 4.0/3.0 x4 M.2 with Thermal Guard
- SuperSpeed USB 3.2 Gen2x2 Type-C delivers up to 20Gb/s transfer speeds
- Pre-installed IO shield for easy and quick installation
- RGB Fusion 2.0 with multi-zone addressable LED light show design
- Smart Fan 6 features multiple temperature sensors and hybrid fan headers with Fan Stop
Product Specification
| Product Type | Motherboard - micro ATX |
| Chipset Type | Intel Z690 |
| Processor Socket | LGA1700 Socket |
| Max Processors Qty | 1 |
| Compatible Processors | Core i5, Core i7, Core i9 (supports 12th Generation Intel Core) |
| Supported RAM | Supported RAM |
| Max Size | 128 GB |
| Technology | DDR4 |
| Bus Clock | 2400 MHz, 2133 MHz, 2800 MHz, 3000 MHz, 2666 MHz, 2933 MHz, 3300 MHz (O.C.), 3400 MHz (O.C.), 3333 MHz (O.C.), 3466 MHz (O.C.), 3733 MHz (O.C.), 3600 MHz (O.C.), 3800 MHz (O.C.), 3666 MHz (O.C.), 3866 MHz (O.C.), 4000 MHz (O.C.), 4133 MHz (O.C.), 4500 MHz (O.C.), 4400 MHz (O.C.), 4300 MHz (O.C.), 4266 MHz (O.C.), 4600 MHz (O.C.), 4700 MHz (O.C.), 4800 MHz (O.C.), 3200 MHz, 4933 MHz (O.C.), 5000 MHz (O.C.), 5333 MHz (O.C.), 5133 MHz (O.C.) |
| Supported RAM Integrity Check | Non-ECC, ECC (operate in non-ECC mode) |
| Registered or Buffered | Unbuffered |
| Features | Dual channel memory architecture, supported ECC modules operate in non-ECC mode, Intel Extreme Memory Profiles (XMP) 3.0 |
| Audio | Audio |
| Type | HD Audio (8-channel) |
| Compliant Standards | High Definition Audio |
| LAN | LAN |
| Network Controller | Intel AX201 |
| Network Interfaces | 2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax, Bluetooth 5.2 |
| Expansion / Connectivity | Expansion / Connectivity |
| Expansion Slots | 1 x CPU ¦ 4 x DIMM 288-pin ¦ 1 x PCIe 5.0 x16 ¦ 1 x PCIe 3.0 x16 (x4 mode) |
| Storage Interfaces | SATA-600 -connectors: 6 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 ¦ PCIe 4.0 -connectors: 3 x M.2 |
| Interfaces | 1 x USB-C Gen2x2 ¦ 1 x USB 3.2 Gen 2 ¦ 1 x LAN (2.5Gigabit Ethernet) ¦ 1 x TOSLINK ¦ 1 x audio line-out - mini-jack ¦ 1 x microphone - mini-jack ¦ 1 x HDMI ¦ 1 x DisplayPort ¦ 4 x USB 3.2 Gen 1 ¦ 4 x USB 2.0 |
| Internal Interfaces | 2 x USB 3.2 Gen 1 - header ¦ 1 x USB-C Gen2 - header ¦ 4 x USB 2.0 - header |
| Power Connectors | 4-pin ATX12V connector, 24-pin main power connector, 8-pin ATX12V connector |
| Features | Features |
| BIOS Type | AMI |
| BIOS Features | WfM 2.0 support, UEFI BIOS, SMBIOS 2.7 support, DMI 2.7 support, ACPI 5.0 support |
| Hardware Monitoring | CPU core temperature, chassis temperature, CPU fan tachometer, chassis fan tachometer, system voltage, CPU overheating protection, CPU core voltage, water cooling flow rate, fan fail warning |
| Hardware Features | Q-Flash, On/Off Charge, Ultra Durable, AMD CrossFireX technology support, AMD Quad CrossFireX technology support, Q-Flash Plus, Game Boost, Intel Optane Memory Ready, RGB FUSION 2.0, GIGABYTE Smart Fan 6, Thermal Reactive Armor, MultiKey, NanoCarbon Fins-Array III Heatsink and Direct Touch Heatpipe II, 20+1+2 Phase Power Design |
| Miscellaneous | Miscellaneous |
| Software Included | Norton Internet Security, @BIOS, EasyTune, Xpress Install, cFosSpeed, GIGABYTE Fast Boot, GIGABYTE Smart Backup |
| Compliant Standards | DisplayPort 1.4, HDCP 2.3 |
| Width | 24.4 cm |
| Depth | 24.4 cm |
Features - GigaByte - Z690M A ELITE AX DDR4
CPU Socket
- Socket 1700
More Details
Product Code
03:184691
EAN Code
4719331827908
Manufacturer
GigaByte
