Grandstream GWN7660 / Radio access point / Wi-Fi 6 / 2.4 GHz, 5 GHz | GWN7660
GWN7660
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
Special Features
- 1.77Gbps aggregate wireless throughput and 2x Gigabit Ethernet ports
- Dual-band 2x2:2 MUMIMO with DL/UL OFDMA technology
- Self-power adaptation upon auto detection of PoE or PoE+
- Supports 256 concurrent Wi-Fi client devices
- Advanced QoS to ensure real-time performance of low-latency applications
- Up to 175-meter coverage range
- Embedded controller can manage up to 50 local GWN series APs; GWN
- Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
Product Specification
| Device Type | Radio access point |
| Ruggedized Design | Indoor |
| Width | 18.04 cm |
| Depth | 18.04 cm |
| Height | 4.08 cm |
| Weight | 443 g |
| Networking | Networking |
| Form Factor | External |
| Connectivity Technology | Wireless |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax |
| Frequency Band | 2.4 GHz, 5 GHz |
| Max Range Open Space | 175 m |
| Performance | Maximum data rate (2.4 GHz): 573.5 Mbps ¦ Maximum data rate (5 GHz): 1201 Mbps ¦ Channel bandwidth (5 GHz): 20 / 40 / 80 MHz ¦ Channel bandwidth (2.4 GHz): 20 / 40 MHz |
| Capacity | Maximum number of configured SSIDs: 32 ¦ Number of concurrent clients: 256 |
| Features | VLAN support, IPv6 support, wall mountable, Wi-Fi Multimedia (WMM) support, Multiple SSID support, IPv4 support, ceiling mountable, security lock slot (cable lock sold separately), Type of Service (ToS), Advanced QoS, 2x2:2 MU-MIMO technology, security slot (Kensington security lock compatible) |
| Encryption Algorithm | AES, TKIP, WPA-PSK, WPA2-PSK, WPA-Enterprise, WPA2-Enterprise, WEP, WPA3 |
| Compliant Standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.1x, IEEE 802.11e, IEEE 802.11n, IEEE 802.3at, IEEE 802.11ac, IEEE 802.3ax |
| Aerial | Aerial |
| Antenna | Internal |
| Antenna Qty | 2 |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 2 x 1000Base-T (PoE+) - RJ-45 |
| Miscellaneous | Miscellaneous |
| Included Accessories | Wall mounting kit, ceiling mounting kit |
| Compliant Standards | IC, FCC, RCM |
| Power | Power |
| Power Over Ethernet (PoE) Supported | PoE+ |
| Power Consumption Operational | 9 Watt |
| Dimensions & Weight (Shipping) | Dimensions & Weight (Shipping) |
| Shipping Width | 22.85 cm |
| Shipping Depth | 22 cm |
| Shipping Height | 7.9 cm |
| Shipping Weight | 774 g |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 45 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
