HGST Ultrastar 7K6000 HUS726040ALA610 / Hard drive / 4 TB / internal / 3.5" / SATA 6Gb/s / 7200 rpm / buffer: 128 MB | 0F23090
HGST Ultrastar 7K6000 HUS726040ALA610 / Hard drive / 4 TB / internal / 3.5" / SATA 6Gb/s / 7200 rpm / buffer: 128 MB | 0F23090
Description
Corporate and cloud data centers are under extreme pressure to improve the efficiency of storage. To address this data center challenge, HGST introduces Ultrastar 7K6000, delivering plenty of capacity and a standard, 3.5-inch hard drive, for capacity-optimized enterprise applications. Ultrastar 7K6000 provides more capacity and better power efficiency. The Ultrastar 7K6000 also delivers great storage efficiency through the unrivaled performance, achieving higher write performance, even at higher workloads, thanks to HGST media cache architecture, a disk-based caching technology, which provides a large non-volatile cache on the disk. Media cache also allows for improved reliability and data integrity during unexpected power loss.
HGST Ultrastar 7K6000 HUS726040ALA610 / Hard drive | 0F23090
Special Features
- Incredible random write and sequential performance
- Reliable, field-proven 5-disk design
- Improved response time and data management
Product features
- Increasing capacity density
Ultrastar 7K6000 delivers plenty of capacity in a standard, 3.5-inch hard drive, for capacity-optimized enterprise applications. Ultrastar 7K6000 provides more capacity and better power efficiency. The 7K6000 is designed for traditional and rapidly growing scale-out storage applications, including object, block and file storage architectures, providing huge capacity, fast 7,200 RPM performance and the optimal acquisition cost. - The technology to improve storage efficiency
Ultrastar 7K6000 also delivers great storage efficiency through its stunning performance, achieving higher random write performance, thanks to HGST media cache architecture, a disk-based caching technology, which provides a large non-volatile cache on the disk. Media cache also allows for improved reliability and data integrity during unexpected power loss. Other performance-enhancing feature is high areal density for faster sequential performance. The 7K6000 offers a 12 Gb/s SAS interface for easy integration into high performance data centers.
Product Specification
Device Type | Hard drive - internal |
Capacity | 4 TB |
Form Factor | 3.5" x 1/3H |
Interface | SATA 6Gb/s |
Buffer Size | 128 MB |
Bytes per Sector | 512 |
Features | Rotational Vibration Safeguard (RVS), Advanced Format technology, 24x7 continuous operation, Instant Secure Erase (ISE), media caching technology, Rebuild Assist mode, non-volatile cache |
Width | 101.6 mm |
Depth | 147 mm |
Height | 26.1 mm |
Weight | 715 g |
Drive Transfer Rate | 600 MBps (external) |
Internal Data Rate | 202 MBps |
Seek Time | 7.6 ms (average) |
Average Latency | 4.16 ms |
Spindle Speed | 7200 rpm |
MTBF | 2,000,000 hours |
24x7 Operation | Yes |
Non-Recoverable Errors | 1 per 10^15 |
Load / Unload Cycles | 600,000 |
Interfaces | 1 x SATA 6 Gb/s - 7 pin Serial ATA |
Compatible Bay | 3.5" x 1/3H |
Power Consumption | 9.1 Watt (active) ¦ 7.1 Watt (low power idle) |
Compliant Standards | EcoTrac |
Service & Support | Limited warranty - 5 years |
Min Operating Temperature | 5 °C |
Max Operating Temperature | 60 °C |
Shock Tolerance (operating) | 70 g @ 2 ms half-sine pulse |
Shock Tolerance (non-operating) | 300 g @ 1 ms half-sine pulse |
Vibration Tolerance (operating) | 0.67 g @ 5-500 Hz |
Vibration Tolerance (non-operating) | 1.04 g @ 5-500 Hz |
