Hikvision Pro Series (All) DS-2CD2183G2-IU - Network surveillance camera - dome - dustproof / waterproof / vandal-proof - colour (Day&Night) - 8 MP - 3840 x 2160 - M12 mount - fixed iris - fixed focal - audio - LAN 10/100 - MJPEG, H.264, H.265, H.265+, H.
Please sign in so that we can notify you about a reply
Special Fetures
- High quality imaging
- Clear imaging against strong backlight due to true WDR technology
- Efficient H.265+ compression technology
- Focus on human and vehicle targets classification based on deep learning
- Built-in microphone for real-time audio security
- Water and dust resistant and vandal-resistant
Product Specification
| Device Type | Network surveillance camera |
| Audio Support | Yes: built-in microphone |
| Audio Formats | AAC, PCM, G.726, MP3, G.722.1, MP2L2, G.711a, G.711u |
| Form Factor | Dome |
| Connectivity Technology | Wired |
| Width | 12.14 cm |
| Depth | 12.14 cm |
| Height | 9.22 cm |
| Weight | 550 g |
| Camera | |
| Type | Colour - Day&Night - fixed - dustproof / waterproof / vandal-proof |
| Digital Video Format | MJPEG, H.264, H.265, H.265+, H.264+ |
| Max Digital Video Resolution | 3840 x 2160 |
| Motion Detection | Yes |
| Exposure Range | 1/3 sec - 1/100000 sec |
| Minimum Illumination | 0.005 lux - colour - F1.6 - AGC on ¦ 0 lux - B&W - infrared LEDs on |
| Infrared LEDs | Yes |
| Infrared Distance | 30 m |
| Video Capture | 3840 x 2160, 50 Hz @ 20 fps ¦ 3200 x 1800, 50 Hz @ 25 fps ¦ 2688 x 1520, 50 Hz @ 25 fps ¦ 1920 x 1080, 50 Hz @ 25 fps ¦ 1280 x 720, 50 Hz @ 25 fps ¦ 3840 x 2160, 60 Hz @ 20 fps ¦ 3200 x 1800, 60 Hz @ 30 fps ¦ 2688 x 1520, 60 Hz @ 30 fps ¦ 1920 x 1080, 60 Hz @ 30 fps ¦ 1280 x 720, 60 Hz @ 30 fps ¦ 640 x 480, 50 Hz @ 25 fps ¦ 640 x 360, 50 Hz @ 25 fps ¦ 640 x 480, 60 Hz @ 30 fps ¦ 640 x 360, 60 Hz @ 30 fps |
| Features | Backlight Compensation (BLC), Wide Dynamic Range (WDR), Highlight Compensation (HLC), Variable Bitrate (VBR), Constant Bitrate (CBR), intrusion detection, 3D Digital Noise Reduction Technology, Line Crossing Detection, DORI coverage, Vehicle Detection, human detection, Face Capture, AcuSense technology |
| Image Sensor | |
| Type | 8 MP PS CMOS 1/2.8" |
| Lens Construction | |
| Type | M12 mount - fixed focal |
| Focal Length | 2.8 mm |
| Lens Iris | F/1.6 fixed iris |
| Horizontal Field of View (degree) | 107 |
| Vertical Field of View (degree) | 57 |
| Diagonal Field of View (degree) | 128 |
| Panning | |
| Range (degree) | 0 to 355 |
| Tilting | |
| Range (degree) | 0 to 75 |
| Interfaces | |
| Network Interface | Ethernet 10Base-T/100Base-TX |
| Network Protocols | DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ICMP, SNMP, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, PPPoE, IGMP, SSL, QOS |
| Expansion / Connectivity | |
| Ports | LAN/power - RJ-45 |
| Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
| Miscellaneous | |
| Compliant Standards | IP67, IK10 |
| Power | |
| Power Requirements | DC 12 V / PoE Class 3 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 15 cm |
| Shipping Depth | 15 cm |
| Shipping Height | 14.1 cm |
| Shipping Weight | 800 g |
| Environmental Parameters | |
| Min Operating Temperature | -30 °C |
| Max Operating Temperature | 60 °C |
| Relative Humidity (operating) | 95% (non-condensing) |
Features - Hikvision - DS-2CD2183G2-IU(2.8MM)
More Details
Product Code
04:385907
EAN Code
6941264095453
Manufacturer
Hikvision
