Aruba 2530-48G-PoE+-2SFP+ / Switch / Managed / 48 x 10/100/1000 (PoE+) + 2 x 10 Gigabit SFP+ / desktop, rack-mountable, wall-mountable / PoE+ (382 W) | J9853A
|
Description The Aruba 2530 Switch Series provides security, reliability, and ease of use for enterprise edge, branch office, and SMB deployments. Fully managed switches deliver Layer 2 capabilities with enhanced access security, traffic prioritization, sFlow, IPv6 host support, and power savings with energy-efficient Ethernet. The Aruba 2530 Switch Series is easy to use and deploy, and delivers consistent wired / wireless user experience. Aruba 2530-48G-PoE+-2SFP+ / Switch / Managed | J9853ASpecial Features
Product features
|
Product Specification
| Device Type | Switch - 48 ports - Managed |
| Enclosure Type | Desktop, rack-mountable, wall-mountable 1U |
| Subtype | Gigabit Ethernet |
| Ports | 48 x 10/100/1000 (PoE+) + 2 x 10 Gigabit SFP+ |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 382 W |
| Performance | Throughput: 101 Mpps ¦ Switching capacity: 136 Gbps |
| MAC Address Table Size | 16000 entries |
| Jumbo Frame Support | 9220 bytes |
| Remote Management Protocol | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH-2, CLI |
| Encryption Algorithm | SSL |
| Authentication Method | RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
| Features | Flow control, DHCP support, BOOTP support, ARP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), port mirroring, IPv6 support, half duplex mode, full duplex mode, SNTP support, sFlow, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Quality of Service (QoS), STP Root Guard, LLDP support, Class of Service (CoS), Generic Attribute Registration Protocol (GARP) |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az |
| Processor | 1 x ARM: 800 MHz |
| RAM | 256 MB DDR3 SDRAM |
| Flash Memory | 128 MB |
| Interfaces | 48 x 1000Base-T - RJ-45 - PoE+ ¦ 2 x Gigabit / 10Gbit LAN - SFP+ ¦ 1 x console - RJ-45 - management ¦ 1 x USB - Type B - management |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 439 Watt |
| Compliant Standards | FCC Class A certified, CISPR 22 Class A, CISPR 24, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, VCCI Class A ITE, EN 61000-3-3, EN55024, EN55022 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, EN 60825, CSA C22.2 No. 60950-1 |
| Width | 44.3 cm |
| Depth | 32.26 cm |
| Height | 4.45 cm |
| Weight | 4.72 kg |
| Service & Support | Limited warranty - advance parts replacement - lifetime |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 45 °C |
| Humidity Range Operating | 15 - 95% (non-condensing) |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 15 - 90% (non-condensing) |
Features - Hewlett Packard - J9853A
More Details
Product Code
03:517275
EAN Code
0887758614693
Manufacturer
Hewlett Packard
