HPE Aruba Instant On 1930 8G Class4 PoE 2SFP 124W Switch / Switch / L2+ / Managed / 8 x 10/100/1000 (PoE+) + 2 x Gigabit SFP / rack-mountable / PoE+ (124 W) | JL681A
HPE Aruba Instant On 1930 8G Class4 PoE 2SFP 124W Switch / Switch / L2+ / Managed / 8 x 10/100/1000 (PoE+) + 2 x Gigabit SFP / rack-mountable / PoE+ (124 W) | JL681A
€340.67 inc. VAT
JL681A#ABB
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
HPE Aruba Instant On 1930 8G Class4 PoE 2SFP 124W Switch / Switch / L2+ / Managed / 8 x 10/100/1000 (PoE+) + 2 x Gigabit SFP / rack-mountable / PoE+ (124 W) | JL681A
Product Specification
| Device Type | Switch - 8 ports - L2+ - Managed |
| Enclosure Type | Rack-mountable 1U |
| Subtype | Gigabit Ethernet |
| Ports | 8 x 10/100/1000 (PoE+) + 2 x Gigabit SFP |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 124 W |
| Performance | Throughput: 14.88 Mpps ¦ Switching capacity: 20 Gbps ¦ Latency (100 Mbps): 5.2 µs ¦ Latency (1 Gbps): 3 µs |
| Capacity | Routing table entries (static): 32 |
| MAC Address Table Size | 8K entries |
| Jumbo Frame Support | 9216 bytes |
| Routing Protocol | IGMPv2, IGMP, static IPv4 routing, MSTP, RSTP, STP |
| Remote Management Protocol | SNMP, RMON, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SCP, DHCP, IPv4, IPv6 |
| Encryption Algorithm | SSL |
| Authentication Method | RADIUS |
| Features | Flow control, DHCP support, ARP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, port mirroring, manageable, IPv6 support, half duplex mode, full duplex mode, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, Trusted Platform Module (TPM), IPv4 support, LACP support, LLDP support, Link Aggregation Control Protocol (LACP), Class of Service (CoS), SNMP support, 1.5MB packet buffer, Bridge protocol data unit (BPDU), LLDP-MED, Energy-Efficient Ethernet (EEE) |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.2af |
| Processor | 1 x ARM Cortex-A9: 800 MHz |
| RAM | 512 MB |
| Flash Memory | 256 MB |
| Interfaces | 8 x 1000Base-T RJ-45 ¦ 2 x Gigabit LAN SFP |
| Power Device | Internal power supply |
| Power Provided | 150.2 Watt |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| MTBF | 95 years |
| Compliant Standards | VCCI, CISPR 24, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-3-3, UL 60950-1, IEC 60950-1, EN 60950-1, EN 60825-1, CNS 13438, EN 55024:2010, FCC CFR47 Part 15 A, ICES-003 issue 6 Class A, IEC 62368-1, UL 62368-1 Second Edition, CISPR 32 Class A, EN 62368-1:2014, CAN/CSA-C22.2 No. 60950-1, CISPR 35, EN 55035:2017, EN 55032:2015+AC:2016 Class A |
| Width | 25.4 cm |
| Depth | 15.95 cm |
| Height | 4.39 cm |
| Weight | 1.16 kg |
| Service & Support | Limited warranty - lifetime ¦ Technical support - phone consulting - 90 days |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 15 - 95% (non-condensing) |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 15 - 95% (non-condensing) |
Features - Hewlett Packard - JL681A#ABB
General
8-Port
More Details
Product Code
07:118313
EAN Code
0190017355238
Manufacturer
Hewlett Packard
