Intel Celeron G6900 / 3.4 GHz / 2 cores / 2 threads / 4 MB cache / LGA1700 Socket / Box | BX80715G6900

Product Specification

Product Type	Processor
Type / Form Factor	Intel Celeron G6900
Number of Cores	Dual-Core
Number of Threads	2 threads
Cache	4 MB
Cache Memory Details	L3 - Smart Cache - 4 MB ¦ L2 - 2.5 MB
Processor Qty	1
Clock Speed	3.4 GHz
Compatible Processor Socket	LGA1700 Socket
Manufacturing Process	10 nm
Thermal Design Power	46 W
Thermal Specification	100 °C
PCI Express Revision	4.0/5.0
PCI Express Configurations	1x16+4, 2x8+4
PCI Express Lanes Qty	20
Architecture Features	Enhanced SpeedStep technology, Execute Disable Bit capability, Intel Virtualization Technology, Intel 64 Technology, streaming SIMD extensions 4.1, streaming SIMD extensions 4.2, Intel AES New Instructions (AES-NI), Thermal Monitoring Technologies, Intel Virtualization Technology for Directed I/O (VT-d), Idle States, Intel VT-x with Extended Page Tables (EPT), Intel Secure Key, Intel Advanced Vector Extensions 2 (AVX2.0), Intel OS Guard, Intel Speed Shift Technology, Intel Optane Memory Supported, Mode-based Execute Control (MBE), Intel Volume Management Device (VMD), Intel Boot Guard, Intel Deep Learning Boost (DL Boost), Intel Control-Flow Enforcement Technology, Intel Gaussian and Neural Accelerator 3.0, Instruction Set 64-bit
Type	Intel UHD Graphics 710
Base Frequency	300 MHz
Max Dynamic Frequency	1.3 GHz
Max Supported Resolution	5120x3200@120Hz (eDP), 7680x4320@60Hz (DP), 4096x2160@60Hz (HDMI)
Features	Intel Clear Video HD Technology, Intel Quick Sync Video, Quad Display Capable
Package Type	Intel Boxed
Service & Support	Limited warranty - 3 years
