Intel Next Unit of Computing Kit NUC7i3BNH / Barebone / mini PC / Core i3 7100U HD Graphics 620 / GigE / WLAN, Bluetooth 4.2 | BOXNUC7i3BNH
BOXNUC7I3BNH
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
Intel Next Unit of Computing Kit NUC7i3BNH / Barebone / mini PC / Core i3 7100U HD Graphics 620 / GigE / WLAN, Bluetooth 4.2 | BOXNUC7i3BNH
|
Description The Intel NUC Mini PC reimagines desktop PC into a smaller package, letting you work, study, or play in any room. Special Features
Product features
|
Product Specification
| Type | PC barebone |
| Product Form Factor | Mini PC |
| Built-in Devices | Infrared receiver |
| CPU | Intel Core i3 (7th Gen) 7100U / 2.4 GHz |
| Number of Cores | Dual-Core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| CPU Upgradability | Not upgradable |
| Processor Main Features | Hyper-Threading Technology, Intel Execute Disable Bit, Enhanced Intel SpeedStep Technology, Intel Virtualization Technology, Intel 64 Technology, Intel AES New Instructions |
| Installed Size | 3 MB |
| Cache Per Processor | 3 MB |
| Installed Size | 0 MB / 32 GB (max) |
| Technology | DDR4 SDRAM |
| Effective Memory Speed | 2133 MHz |
| Form Factor | SO-DIMM 260-pin |
| Features | Dual channel memory architecture |
| Type | No HDD |
| Type | 1 x SATA |
| Controller Interface Type | SATA 6Gb/s |
| Type | - M.2 Card |
| Type | Card reader |
| Supported Flash Memory Cards | SDXC UHS-I Memory Card |
| Monitor Type | None. |
| Graphics Processor | Intel HD Graphics 620 |
| Video Interfaces | HDMI, DisplayPort |
| Sound Output Mode | 7.1 channel surround |
| Compliant Standards | High Definition Audio |
| Wireless LAN Supported | Yes |
| Wireless NIC | Intel Dual Band Wireless-AC 8265 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 4.2 |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 4.2 |
| Bays | 1 (total) / 1 (free) x internal 2.5" ¦ 1 (total) / 1 (free) x internal M.2 2242/2280 |
| Slots | 2 (total) / 2 (free) x SO-DIMM 260-pin |
| Interfaces | 4 x USB 3.0 - Type A (2 front, 2 rear) (one of them is fast-charging) ¦ 2 x USB 2.0 (2 internal) ¦ 1 x HDMI ¦ 1 x headphones/microphone - mini-jack ¦ 1 x LAN (Gigabit Ethernet) - RJ-45 ¦ 1 x DisplayPort/USB-C 3.1 Gen2 ¦ 2 x SATA-600 (2 internal) |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Compliant Standards | Plug and Play, ICES-003, EN55024, FCC, UL 60950-1, IEC 60950-1, EN 60950-1, AS/NZS 4268, FCC CFR47 Part 15 C, FCC CFR47 Part 15 B, CAN/CSA C22.2 No. 60950-1, VCCI V-3, VCCI V-2, EN 62311, VCCI V-4, KN24, EN 300 328, CNS 13438, RoHS 2011/65/EU, EN 301.489-17, WEEE 2012/19/EU, EN 301 489-1, EN 300 893, CISPR32/EN55032, KN32, AS/NZS 2772.2, FCC CFR47 Part 15 E |
| Device Type | Power adapter |
| Power Provided | 65 Watt |
| Width | 11.5 cm |
| Depth | 11.1 cm |
| Height | 5.1 cm |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
Features - Intel - BOXNUC7I3BNH
CPU Type
- Intel Core i3
More Details
Product Code
03:105408
EAN Code
5032037088473
Manufacturer
Intel
