Intel NUC Kit 8 Pro Kit NUC8i3PNK Barebone mini PC Core i3 8145U | BKNUC8I3PNK
BKNUC8I3PNK
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
Intel Next Unit of Computing Kit 8 Pro Kit / NUC8i3PNK / Barebone / mini PC / 1 x Core i3 8145U / 2.1 GHz / RAM 0 GB / UHD Graphics 620 / GigE / WLAN: 802.11a/b/g/n/ac, Bluetooth 5.0 | BKNUC8I3PNK
Description
Intel NUC 8 Pro Mini PCs, boards, and kits are built for business, with a range of 8th Gen Intel Core processors that deliver powerful performance for embedded loT, surveillance, meeting rooms, and more.Systems with Intel Core processors feature the Intel vPro platform for remote management, stability, and security. Every system features new capabilities, including a Thunderbolt 3 port, plus USB 3.1 Gen 2 ports that transfer data at 10Gbps - 2X faster than the previous generation.
Intel NUC Kit 8 Pro Kit NUC8i3PNK Barebone mini PC Core i3 8145U | BKNUC8I3PNK
Special Features
- Superior processing and graphics
- Stunningly small form factor
- Advanced technology
Product features
- Superior processing and graphics
Visibly smart graphics using the advanced processor deliver amazing performance and visually stunning graphics. - Stunningly small form factor
The compact form factor unlocks a world of potential design applications, from digital signage and kiosks to portable innovations. - Advanced technology
The NUC features two sockets for expandability of memory, two mini-card connectors for flexible support of wireless and hard drive configurations, BIOS vault technology, fast boot and the Visual BIOS. The NUC also supports The Anti-Theft technology, providing hardware intelligence, designed to protect your device and its data, if its lost or stolen.
Product Specification
| Type | PC barebone |
| Product Form Factor | Mini PC |
| CPU | Intel Core i3 (8th Gen) 8145U / 2.1 GHz |
| Max Turbo Speed | 3.9 GHz |
| Number of Cores | Dual-Core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| CPU Upgradability | Not upgradable |
| Processor Main Features | Intel Virtualization Technology, Intel AES New Instructions |
| Installed Size | 4 MB |
| Cache Per Processor | 4 MB |
| Installed Size | 0 GB / 64 GB (max) |
| Technology | DDR4 SDRAM |
| Rated Memory Speed | 2400 MHz |
| Form Factor | SO-DIMM 260-pin |
| Slots | 2 (Total) / 2 (empty) |
| Type | No HDD |
| Type | 1 x SATA |
| Controller Interface Type | SATA 6Gb/s |
| RAID Level | RAID 0, RAID 1 |
| Type | No optical drive |
| Monitor Type | None. |
| Graphics Processor | Intel UHD Graphics 620 |
| Video Interfaces | HDMI, DisplayPort |
| Max Monitors Supported | 3 |
| Sound Output Mode | 7.1 channel surround |
| Compliant Standards | High Definition Audio |
| Ethernet Controller | Intel I219-LM |
| Wireless LAN Supported | Yes |
| Wireless NIC | Intel Wireless-AC 9560 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0 |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0 |
| Slots | 1 (total) / 1 (free) x M.2 Card - 2242/2280 (Key M) |
| Interfaces | 3 x USB 3.1 - Type A (2 front, 1 rear) ¦ 1 x Thunderbolt 3/USB-C 3.1 - Type C ¦ 2 x HDMI ¦ 1 x LAN (Gigabit Ethernet) - RJ-45 ¦ 1 x USB 2.0 - Type A (1 rear) |
| Compliant Standards | ICES-003, EN55024, AS/NZS 4268, BSMI CNS 13438, FCC CFR47 Part 15 C, FCC CFR47 Part 15 B, REACH, EN 62311, EN 300.440, EN 300 328, EN 301 489-1, CISPR32/EN55032, KN32, KN35, AS/NZS 2772.2, EN 301 893, IEC/EN/UL 60950-1, FCC CFR47 Part 15 E, EN 301 489-3, EU RoHS, IEC/EN/UL 62368-1, EN 301 489-17, ARPANSA, AS/NZS CISPR 32, VCCI 32 |
| Device Type | Power adapter |
| Nominal Voltage | DC 12 - 24 V |
| Power Provided | 90 Watt |
| Service & Support | Limited warranty - 3 years |
| Width | 11.7 cm |
| Depth | 11.2 cm |
| Height | 5.3 cm |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 35 °C |
Features - Intel - BKNUC8I3PNK
CPU Type
- Intel Core i3
More Details
Product Code
1359628
EAN Code
5032037180313
Manufacturer
Intel
