Kingston ValueRAM / DDR4 / module / 8 GB / SO-DIMM 260-pin / 3200 MHz / PC4-25600 / CL22 / 1.2 V / unbuffered / non-ECC | KVR32S22S6/8
Product Specification
| Capacity | 8 GB |
| Upgrade Type | Generic |
| Width | 69.9 mm |
| Depth | 2.45 mm |
| Height | 30 mm |
| Type | DRAM memory module |
| Technology | DDR4 SDRAM |
| Form Factor | SO-DIMM 260-pin |
| Module Height (inch) | 1.18 |
| Speed | 3200 MHz (PC4-25600) |
| Latency Timings | CL22 (22-22-22) |
| Data Integrity Check | Non-ECC |
| Features | Single rank, On-Die Termination (ODT), Serial Presence Detect (SPD), sixteen banks, Low-power auto self refresh (LPASR), DBI mode support, unbuffered |
| Module Configuration | 1024 x 64 |
| Chips Organization | 1024 x 16 |
| Voltage | 1.2 V |
| Lead Plating | Gold |
| Compliant Standards | RoHS, halogen-free, JEDEC |
| Service & Support | Limited lifetime warranty (Russia - 10 years) |
Features - Kingston - KVR32S22S6/8
More Details
Product Code
03:145139
EAN Code
0740617310887
Manufacturer
Kingston
