Kyocera ECOSYS M5526cdw / Multifunction printer / colour / laser / Legal (216 x 356 mm)/A4 (210 x 297 mm) (original) / A4/Legal (media) / up to 26 ppm (copying) / up to 26 ppm (printing) / 300 sheets / 33.6 Kbps / USB 2.0, Gigabit LAN, USB h | 1102R73NL0
Please sign in so that we can notify you about a reply
Product Specification
| Device Type | Multifunction printer |
| Fax Type | Plain paper |
| Printing Technology | Laser - colour |
| Display Diagonal Size | 4.3" |
| Display Features | Touch screen |
| Connection Availability | Yes |
| Interface | USB 2.0, Gigabit LAN, USB host, Wi-Fi |
| AirPrint Enabled | Yes |
| Office Machine Features | Scan to e-mail, scan to FTP, scan to SMB, scan to USB host |
| Memory | Memory |
| Standard Memory | 512 MB |
| Max Supported Memory | 1.5 GB |
| Supported Flash Memory | SD Memory Card, SDHC Memory Card |
| Copying | Copying |
| Max Copying Speed | Up to 26 ppm (mono) / up to 26 ppm (colour) |
| Max Copying Resolution | Up to 600 x 600 dpi (mono) / up to 600 x 600 dpi (colour) |
| Grayscale Half-Tones | 256 |
| Max Document Enlargement | 400% |
| Max Document Reduction | 25% |
| Maximum Copies | 999 |
| Automatic Duplexing | Yes |
| Copying Features | 2 on 1, 4 on 1, ID Card Copy, electronic sorting, Auto Color Mode, Scan-once-copy-many |
| Printing | Printing |
| Max Printing Resolution | Up to 9600 x 600 dpi (mono) / up to 9600 x 600 dpi (colour) |
| Max Printing Speed | Up to 26 ppm (mono) / up to 26 ppm (colour) |
| Printer Drivers / Emulations | PCL 6, PostScript 3, PCL 5c, KPDL3, PCL 6 (XL), XPS, PRESCRIBE IIc |
| Automatic Duplexing | Yes |
| First Print Out Time B/W | 9.5 sec |
| First Print Out Time Colour | 10.5 sec |
| Scanning | Scanning |
| Automatic Duplexing | Yes |
| Optical Resolution | 600 x 600 dpi |
| Fax Machine | Fax Machine |
| Compatibility | Super G3 |
| Max Transmission Speed | 33.6 Kbps |
| Data Compression System | MH, MR, MMR, JBIG |
| Reception Memory Capacity | Up to 256 pages |
| Fax Machine Features | Fax Machine Features |
| Speed Dialing | 100 station(s) |
| Remote Fax Retrieval (Polling) | Yes |
| Features | Fax polling, Duplex Fax |
| Document & Media Handling | Document & Media Handling |
| Max Original Size | Legal (216 x 356 mm)/A4 (210 x 297 mm) |
| Original Type | Sheets |
| Document Feeder Capacity | 50 sheets |
| Min Media Size | 70 x 148 mm |
| Max Media Size | A4/Legal |
| Min Media Weight | 60 g/m² |
| Max Media Weight | 220 g/m² |
| Supported Media Type | Plain paper |
| Supported Media Sizes | ANSI A (Letter) (216 x 279 mm), Legal (216 x 356 mm), A4 (210 x 297 mm), A5 (148 x 210 mm), B5 (176 x 250 mm), A6 (105 x 148 mm), B6 (125 x 176 mm), 70 x 148 mm |
| Standard Media Capacity | 300 sheets |
| Max Media Capacity | 550 sheets |
| Bypass Feeder Capacity | 50 sheets |
| Output Trays Capacity | 150 sheets |
| Document & Media Handling Details | Input tray - 250 sheets size: A6 (105 x 148 mm) - Legal (216 x 356 mm)/A4 (210 x 297 mm) weight: 60 g/m² - 163 g/m² ¦ Bypass tray - 50 sheets size: 70 x 148 mm - Legal (216 x 356 mm)/A4 (210 x 297 mm) weight: 60 g/m² - 220 g/m² ¦ ADF - 50 sheets size: A6 (105 x 148 mm) - Legal (216 x 356 mm)/A4 (210 x 297 mm) weight: 50 g/m² - 160 g/m² ¦ Output tray - 150 sheets |
| Speed Details | Printing: up to 26 ppm (A4) - colour ¦ Printing: up to 26 ppm (A4) - B/W ¦ Copying: up to 26 ppm (A4) - B/W ¦ Copying: up to 26 ppm (A4) - colour ¦ Scanning: up to 30 ipm (A4) - B/W ¦ Scanning: up to 23 ipm (A4) - colour ¦ Scanning: up to 24 ipm (A4) - B/W duplex ¦ Scanning: up to 16 ipm (A4) - colour duplex |
| Connections | Connections |
| Interfaces | 1 x USB 2.0 - 4 pin USB Type B ¦ 1 x USB host - 4 pin USB Type A ¦ 1 x Gigabit LAN - RJ-45 |
| Security Protocols & Features | SSL, IPsec |
| Operating System Support | UNIX, Linux, MS Windows, Apple Mac OS X 10.8 or later |
| Power | Power |
| Voltage Required | AC 230 V (50Hz) |
| Power Consumption Operational | 375 Watt |
| Power Consumption Standby | 41 Watt |
| Power Consumption Sleep | 1 Watt |
| Miscellaneous | Miscellaneous |
| Warm-Up Time | 29 sec |
| First Copy Out Time B/W | 8 sec |
| First Copy Out Time Colour | 10 sec |
| Consumables Included | 1 x Cartridge (cyan) - up to 1200 pages ¦ 1 x Cartridge (magenta) - up to 1200 pages ¦ 1 x Cartridge (yellow) - up to 1200 pages ¦ 1 x Cartridge (black) - up to 1200 pages |
| Compliant Standards | ISO 9001, ISO 14001, AS/NZS 3260, ISO 7779, ISO 9296 |
| Environmental Standards | Environmental Standards |
| ENERGY STAR Certified | Yes |
| Dimensions & Weight | Dimensions & Weight |
| Width | 41.7 cm |
| Depth | 42.9 cm |
| Height | 49.5 cm |
| Weight | 26 kg |
| Environmental Parameters | Environmental Parameters |
| Sound Emission | 30 dBA (idle) / 49 dBA (operating) |
Features - Kyocera - 1102R73NL0
More Details
Product Code
03:186539
EAN Code
0632983036594
Manufacturer
Kyocera
